15
Updated
28/02/01
xSeries 200 I/O Options
Part
Number
Description Adapter
Length
PCI
Support
Slots
Supported
1
-
SCSI Storage Controllers
2, 3
37L6091 ServeRAID-4L Ultra160 SCSI Controller
4
Full 32/64-bit 2...5
37L6080 ServeRAID-4M Ultra160 SCSI Controller
5
Full 32/64-bit 2...5
19K4646 PCI Wide Ultra160 SCSI Adapter
6
Half 32-bit 2...5
02K3454 PCI Fast/Wide Ultra SCSI Adapter Half 32-bit 2...5
Networking
7
Ethernet
09N9901 10/100 EtherLink Server Adapter by 3Com Half 32-bit 1...5
19K4401 Netfinity Gigabit Ethernet Adapter Half 32/64-bit 1...5
06P3601 10/100 Ethernet Server Adapter Half 32-bit 1...5
06P3701 Gigabit Ethernet SX Server Adapter (fibre optic cabling interface) Half 32/64-bit 1...5
Token Ring
8
34L0701 Token-Ring 16/4 PCI Adapter 2 with Wake on LAN
8
Half 32-bit 1...5
34L5001 16/4 Token-Ring PCI Management Adapter
8
Half 32-bit 1...5
34L5201 High-speed 100/16/4 Token-Ring PCI Management Adapter
8
Half 32-bit 1...5
Communications
9
37L14xx Serial I/O SST 8, 16 and 128 Port Adapters
10
Half 32-bit 2...5
10
1. The xSeries 200 has five full-length, 33 MHz PCI expansion slots. The number of available slots is model specific.
2. Some models of the xSeries 200 include a single channel Ultra160 SCSI Adapter with a five drop multi-mode terminated LVD SCSI Cable. All other models include dual-channel EIDE controllers
and require an optional SCSI adapter for SCSI functionality. See the At-A-Glance chart for model attributes
3. Storage controllers are supported in slots two through five only. Slots two and four, and slots three and five, are 'paired' in adapter support terms and can only support the same type of adapter.
i.e slots two and four can both only contain storage controllers or they can both only contain network adapters. Similarly with slots three and five
4. ServeRAID-4L Ultra160 SCSI Controller is powered by a 100 MHz Intel i960 processor and provides a single channel, 16 MB of ECC cache and either one internal or one external Ultra160 connection.
External connector is 0.8-mm VHDCI.
5. ServeRAID-4M Ultra160 SCSI Controller is powered by a 100 MHz Intel i960 processor and provides two channels, 64 MB of battery-backed ECC cache and two external 0.8-mm VHDCI Ultra160
connectors.
6. PCI Wide Ultra160 SCSI Adapter P/N 19K4646 provides a single channel with one internal connector and a five-drop multi-mode terminated LVD SCSI cable and one external connector with a 0.8-mm
VHDCI connector. Only one of the two connectors may be utilised.
7. xSeries 200 includes an integrated full-duplex, 10.100 Mbps Ethernet controller. Networking adapters are supported in slots one through five. Slots two and four, and slots three and five, are 'paired' in
adapter support terms and can only support the same type of adapter. i.e slots two and four can both only contain network adapters or they can both only contain storage controllers. Similarly with slots three
and five.
8. Wake on LAN is supported for networking adapters designed with this function when installed in slots one through five. Slots two and four, and slots three and five, are 'paired' in adapter support terms and
can only support the same type of adapter. i.e slots two and four can both only contain network adapters or they can both only contain storage controllers. Similarly with slots three and five.
9. xSeries 200 includes two USB ports, two high-speed serial/asynchronous ports, (NS16550A software compatible) and one high-speed parallel port supporting devices using SSP/EPP/ECP protocols adhering
to the IEEE 1284 Standard.
10. See Appendix E for details of Serial I/O options and configuration limitations. A maximum of four Serial I/O adapters (in any combination) may be installed.
External Connector Access
To Next Page
