IBM eServer xSeries User Manual

16
Updated
28/02/01
To access IBM information specific to your country via the World Wide Web, use address: http://www.ibm.com/pc
xSeries 200 Power, Monitors, Accessories
Part Number Description
Power
1,10
94G7448 Rack Power Cable Type C12 (3.7m)
10
Free Standing Uninterruptible Power Supply (UPS)
2
SUP072Y APC Smart-UPS 700
SUP102Y APC Smart-UPS 1000
SUP142Y APC Smart-UPS 1400
Rack Mount Uninterruptible Power Supply (UPS)
2
14RIxxx
9
APC Smart-UPS 1400RMB
3,10
30RIxxx
9
APC Smart-UPS 3000RMB
3,10
37L6862 APC Smart-UPS 5000RMB
4,10
Monitors
5
T3347xx
8
E51 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black
6
T31U2xx
8
E54 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black
6
T32U3xx
8
E74 Color Monitor 17” (403-mm, 15.9” Viewable Image Size), stealth black
6
T274Axx
8
G78 Color Monitor 17” (406.4mm, 16.0” Viewable Image Size), stealth black
6
11AG1xx
8
T54A TFT LCD Color Monitor (306-mm x 230-mm, 15.0” Viewable Image Size), stealth black
7
1. The xSeries 200 includes a 330 W voltage sensing power supply and a single standard country power cord.
2. For runtimes and UPS attributes see Appendix C: UPS Runtime Estimate.
3. Height is 3U. See “Rack and NetBAY” for supported IBM racks.
4. Height is 5U. See “Rack and NetBAY” for supported IBM racks.
5. The xSeries 200 contains a S-3 Savage-4 LT video adapter with 8Mb of video memory plugged into the standard AGP slot.
6. Installation within a rack requires optional Monitor Compartment (P/N94G7444).
7. Installation within a rack requires optional Netfinity Flat Panel Monitor Rack Mount Kit II (P/N 37L6888) and Netfinity Rack Keyboard Tray
(P/N 28L4707). A space saver keyboard may coexist within the same 28L4707 keyboard tray.
8. Where ‘xx’ represents a specific country code: DK=Denmark, IS=Israel, IT=Italy, SD=Saudi Arabia, SA=South Africa, CH=Switzerland,
UK=UK, EU=Europe.
9. Where ‘xxx’ represents the appropriate country code as follows:- DEN=Denmark, ISR=Israel, ITA=Italy, SDI=Saudi Arabia, SAF=South Africa,
SWS=Switzerland, UKM=United Kingdom, EUR=Europe.
10. The xSeries 200 ships with a standard country power cord. If conversion to Rack format is being carried out, Rack Power Cable P/N 94G7448
(type C12), must be ordered to allow connection to a high voltage UPS or PDU.
Part Number Description
Conversion Kits
09N4300 4Ux20D Tower-to-Rack Kit
6
Rack and NetBAY
1,6
930842P Netfinity Enterprise Rack
930842X Netfinity Enterprise Expansion Cabinet
9306900 Netfinity Rack
9306910 Netfinity Rack (Perforated Doors)
36L9703 Netfinity Rack Extension Kit
9306200 Netfinity NetBAY22
36L9702 NetBAY22 Rack Extension Kit
37L6888 Netfinity Flat Panel Monitor Rack Mount Kit II
94G7448 Rack Power Cable Type C12 (3.7m)
6
Keyboard and Mouse
2
28L36xx
5
Space Saver II Keyboard
3, 4
1 Rack installation of an xSeries 200 requires 4Ux20D Tower-to-Rack Kit (P/N 09N4300) and one of the racks listed here. See IBM Netfinity Rack
Cabinet and Options section for IBM rack supported devices.
2. The xSeries 200 includes both a mouse and non-space saver keyboard.
3. Installation within a rack requires optional keyboard tray P/N 28L4707 (stows in “ready-to-use” position).
4. Advanced TrackPoint IV features are not available on IBM Netfinity systems.
5. Where ‘xx’ represents country specific code: 46=Danish , 47=France, 48=Germany, 49=Italian, 50=Spanish, 51=UK English, 44=US English,
19K3831=Switzerland, 19K3832=Sweden/Finland, 19K3833=Portugal, 19K3834=Belgium, 19K3836=Russia, 19K3837=Poland.
6. The xSeries 200 ships with a standard country power cord. If conversion to Rack format and connection to a high voltage UPS or PDU is being
carried out, a Rack Power Cable P/N 94G7448 (type C12), must be ordered.
