Note: For a complete list of all IBM and non-IBM options compatibility with Network Operating Systems and IBM xSeries and Netfinity Servers,
access the IBM ServerProven compatibility pages on the Web at URL http://www.ibm.com/pc/us/compat
xSeries 200 Tape Options
Part
Number
Description Bays
Supported
SCSI
Interface
(bit)
Form
Factor
Termination
Included
68/50-pin
Converter
Included.
Ext. Tape
Enclosures
1
20L0549 10/20GB TR5 Internal IDE Tape Drive
2
2, 4 -
89 mm (3.5”)
SL or 133
mm (5.25”)
HH
- - -
09N4041
12/24GB DDS/3 4-mm Internal SCSI
Tape Drive
3,4,5
28
89 mm (3.5”)
HH or 133
mm (5.25”)
HH
YY
10L7440,
03K8756
09N4042 10/20GB NS Internal SCSI Tape Drive
3,4,5
2, 4 8
89 mm (3.5”)
SL or 133
mm (5.25”)
HH
Y Y
10L7440,
03K8756
00N7991
20/40 GB DDS/4 4-mm Internal Tape
Drive
4,5
2
16 Ultra2
LVD
89 mm (3.5”)
HH or 133
mm (5.25”)
HH
NN/A
10L7440
6
,
03K8756
7
External Tape Enclosures
10L7440 External Half High SCSI Storage Enclosure
8
-8/16DesktopN N -
03K8756 NetMEDIA Storage Expansion Unit EL
9
- 16 Rack Y N -
10L7113 NetMEDIA Systems Management Adapter
10
- 16 LVD - N N 03K8756
Associated Options
00N7956
68-pin External Multimode LVD/SE SCSI
Terminator
- 16 LVD/SE External Y N 10L7440
10K2340 Media Bay Tray and LVD Cable Kit
4,7
- 16 LVD Internal Y N 03K8756
Note: SCSI models include an Ultra160 SCSI controller with a five-drop multi-mode terminated LVD SCSI cable. Single-Ended devices attached to this cable will limit the entire SCSI bus to single-
ended performance. SCSI tape drives and external tape enclosures are supported by PCI Wide Ultra160 SCSI Adapter P/N 19K4646 which includes a five-drop multi-mode LVD SCSI cable and an
external 0.8-mm VHDCI connector.
1. To determine cable requirements, note the tape drive’s SCSI interface, the appropriate SCSI controller from the system configurator section, and the desired enclosure, then refer to Appendix D:
Cables - Storage Units - Controllers.
2. SCSI models include a two-drop EIDE cable for attachment to the CD-ROM and an optional IDE tape drive. EIDE Model P/N K812Xxx includes 10/20GB TR5 Internal IDE Tape Drive P/N 20L0549
as standard.
3.This single-ended device will limit the SCSI bus to which it is attached to Ultra SCSI speeds. To provide a dedicated tape SCSI bus, install PCI Wide Ultra160 SCSI Adapter P/N 19K4646 which
includes a five-drop multi-mode LVD SCSI cable.
4. For RAID configurations (in SCSI models) where the standard SCSI cable is attached to a RAID adapter, the two-drop multi-mode terminated LVD SCSI cable included with Media Bay Tray and
LVD Cable Kit P/N 10K2340 is required, to allow attachment of a SCSI Tape Drive to the standard Ultra160 SCSI Adapter.
5. EIDE models require optional PCI Wide Ultra160 SCSI Adapter P/N 19K4646 which includes a five-drop multi-mode LVD SCSI cable, to allow attachment of a SCSI Tape Drive.
6. Requires 68-pin External Multimode LVD/SE SCSI Terminator P/N 00N7956.
7. LVD support for LVD devices installed in a NetMEDIA Storage Expansion Unit EL P/N 03K8756 requires replacement of the standard single-ended internal cables with one or more (depending on
configuration) cables from Media Bay Tray and LVD Cable Kit P/N 10K2340 which contains a single two-drop mult-mode LVD-SCSI terminated LVD cable. If the standard cables are used for
attachment to LVD devices, single-ended SCSI rules and bus speeds apply.
8. Provides a black desktop 133 mm (5.25”) half-high (HH) tape enclosure. Connector is configurable as 50-pin Centronix or 68-pin high density. Requires either tape drive self termination or 68-pin
External Multimode LVD/SE SCSI Terminator P/N 00N7956.
9. NetMEDIA Storage Expansion Unit EL P/N 03K8756 is a black 3U, 19” rack-mountable tape enclosure which includes two full high (FH) or four half high (HH) extended length 133 mm (5.25”)
bays, two external 68-pin high density connectors and two internal four-drop single-ended terminated 16-bit SCSI cables for device attachment. Two power supplies and two power cords are also
included. Tip: The front rail clips will need to be reversed and screwed in from behind to secure the unit in a Rack Cabinet P/N 930842X.
10. NetMEDIA Systems Management Adapter P/N 10L7113 may be installed in an Expansion Unit P/N 03K8756 to provide repeater function, LVDS interface, aggregate cable lengths up to 12 meters
when attached to an LVD SCSI controller, and auto-termination when the Expansion Unit is powered off. External connector is 0.8-mm VHDCI.
Note: Additional tape details can be found in Appendix A: Tape Drive Attributes
