53
Updated
28/02/01
xSeries 340 / Netfinity 4500R I/O Options
Part
Number
Description Adapter
Length
PCI Support Slots
Supported
SCSI Storage Controllers
1
37L6091 ServeRAID-4L Ultra160 SCSI Controller
2
Full 32/64-bit 1...5
37L6080 ServeRAID-4M Ultra160 SCSI Controller
3
Full 32/64-bit 1...5
37L6889 ServeRAID-4H Ultra160 SCSI Controller
4
Full 32/64-bit 1...5
19K4646 PCI Wide Ultra160 SCSI Adapter
5
Half 32/64-bit 1...5
02K3454 PCI Fast/Wide Ultra SCSI Adapter
6
Half 32-bit 1...5
Fibre Storage Controller
7
00N6881 Netfinity FAStT Host Adapter Half 32/64-bit 1...5
Networking
8
Ethernet
34L1501 Netfinity 10/100 Ethernet PCI Adapter 2 Half 32-bit 1...5
19K4401 Netfinity Gigabit Ethernet Adapter Half 32/64-bit 1...5
06P3601 10/100 Ethernet Server Adapter Half 32-bit 1...5
06P3701 Gigabit Ethernet SX Server Adapter (fibre optic cabling interface) Half 32/64-bit 1...5
09N9901 10/100 EtherLink Server Adapter by 3Com Half 32-bit 1...5
Token Ring
34L0701 Token-Ring 16/4 PCIAdapter 2 with Wake on LAN
9
Half 32-bit 1...5
34L5001 16/4 Token-Ring PCI Management Adapter
9
Half 32-bit 1...5
34L5201 High-Speed 100/16/4 Token-Ring PCI Management Adapter
9
Half 32-bit 1...5
Communications
10
37L14xx Serial I/O SST 8, 16 and 128 Port Adapters
11
Half 32-bit 1...5
11
Systems Management
12
36L96xx
19
Netfinity Advanced System Management PCI Adapter
13
Full 32-bit 1...5
14
03K9309 Netfinity Advanced System Management Interconnect Cable Kit
15
- - -
36L9654 Netfinity Adv6nced System Management Token-Ring Connection
16
-- -
Host Attach
10L7368 Netfinity ESCON Adapter
17
Full 32-bit 1...5
18
1. xSeries 340 / Netfinity 4500R include a dual-port, dual-channel Ultra160 SCSI controller for internal use only. No standard external port is available. See “Internal SCSI Cabling” for cabling alternatives.
Due to Netfinity 4500R’s low profile, some adapters with connectors on the top edge may not have sufficient clearance to attach a cable. Cabling interferences are identified in the footnotes.
2. ServeRAID-4L Ultra160 SCSI Controller is powered by a 100 MHz Intel i960 processor and provides a single channel, 16 MB of ECC cache and either one internal or one external Ultra160 connection.
External connector is 0.8-mm VHDCI.
3. ServeRAID-4M Ultra160 SCSI Controller is powered by a 100 MHz Intel i960 processor and provides two channels, 64 MB of battery-backed ECC cache and two external
0.8-mm VHDCI Ultra160 connectors.
4. ServeRAID-4H Ultra160 SCSI Controller is powered by a 266 MHz PowerPC 750 processor and provides 128 MB of battery-backed ECC cache. The internal connectors are not accessible due to cabling
interference. Four external Ultra160 0.8-mm VHDCI connectors are available.
5. PCI Wide Ultra160 SCSI Adapter (P/N 19K4646) provides a single channel with one internal connector and a five-drop multi-mode terminated LVD SCSI cable and one external connector with a 0.8-mm
VHDCI connector. Only one of the two connectors may be utilised.
6. PCI Fast/Wide Ultra SCSI Adapter provides one external 68-pin high density connector. The internal connectors are not accessible due to a cabling interference.
7. See Fibre Array Solutions section for additional configuration information.
8. xSeries 340 / Netfinity 4500R include a full-duplex, 10/100 Mbps Ethernet PCI controller.
9. The Wake on LAN function of this option is not supported by this server.
10. xSeries 340 / Netfinity 4500R include two USB ports, two serial and one parallel port.
11. See Appendix E for details on Serial I/O options and configuration limitations. A maximum of four Serial I/O adapters (in any combination) may be installed.
12. The Netfinity Advanced Systems Management Processor and Interconnect Bus integrated into xSeries 340 / Netfinity 4500R works with Netfinity Director to provide significant system management
function. When used with optional Netfinity Advanced System Management PCI Adapter (P/N 36L96xx) and Netfinity Advanced System Management Interconnect Cable Kit (P/N 03K9309) additional
management and control of up to 12 service processors from a remote console through a single modem or LAN connection is possible.
13. Includes PCI adapter, Netfinity Advanced System Management Interconnect Cable Kit components and 56-watt AC adapter, which requires a separate power source. Provides an integrated 10/100
Ethernet port and a PCMCIA slot to support optional Netfinity Advanced System Management Token-Ring Connection (P/N 36L9654).
14. A maximum quantity of one is supported.
15. Required for all xSeries and Netfinity Servers containing a standard Advanced System Management Processor that are to be interconnected for system management support through a LAN or modem
connection (Netfinity 5500 models 1xX...4xX are not supported). Optional Netfinity Advanced System Management PCI Adapter (P/N 36L96xx) includes the contents of this option.Up to 12 service
processors may be interconnected (including standard and optional processors) with an aggregate connection length of no more than 91.4 meters (300 ft.). A customer-supplied Ethernet cable is required for
each interconnection.
16. Contains an IBM Turbo 16/4 Token-Ring PCI card, which installs in the PCMCIA card slot of Netfinity Advanced System Management PCI Adapter (P/N 36L96xx), and a PC Card to 9-pin D-Shell
cable which is routed to an available adapter slot opening (reduces available slots by one). The Netfinity Advanced System Management PCI Adapter’s integrated Ethernet port and Netfinity Advanced
System Management Token-Ring Connection cannot be connected or used together.
17. Provides an ESCON MIC and a DB9 Serial Port. Cables are not included but are available through S/390 channels. Contact your IBM representative for additional information.
18. A maximum of two ESCON adapters (installed in non-adjacent slots) are supported in a single server.
19. Where ‘xx’ represents a country specific code: 57=Denmark, 58=South Africa/India, 59=UK, 60=Switzerland, 61=Italy, 62=Israel, 01K7310=Europe, 01K7209=US/Saudi Arabia.
Exterior Connector Access
