xSeries 340 / Netfinity 4500R Power, Monitors, Accessories
Part Number Description
Power
1,8
37L6879 270 W Hot-Swap Redundant Power Supply
8
94G7448 Rack Power Cable Type C12 (3.7m)
8
Uninterruptible Power Supply (UPS)
2
14RIxxx
10
APC Smart-UPS 1400RMB
3
30RIxxx
10
APC Smart-UPS 3000RMB
3
37L6862 APC Smart-UPS 5000RMB
4
Monitors
5
T3347xx
9
E51 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black
6
T31U2xx
9
E54 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black
6
T32U3xx
9
E74 Color Monitor 17” (403-mm, 15.9” Viewable Image Size), stealth black
6
T274Axx
9
G78 Color Monitor 17” (406.4-mm, 16” Viewable Image Size), stealth black
6
11AG1xx
9
T54A TFT LCD Color Monitor (306-mm x 230-mm, 15.0” Viewable), stealth black
7
1. xSeries 340 / Netfinity 4500R include a single 270 W, hot-swap power supply and a single standard country power cord. Power
supply redundancy can be achieved with the addition of optional 270 W Hot-Swap Redundant Supply P/N 37L6879.
2. For runtimes and UPS attributes see Appendix C: UPS Runtime Estimate.
3. Height is 3U. See “Rack and NetBAY” for supported IBM racks.
4. Height is 5U. See “Rack and NetBAY” for supported IBM racks.
5. xSeries 340 / Netfinity 4500R use an SVGA controller (S3 Savage4 chipset) with 8 MB of video memory.
6. Installation within a rack requires optional Monitor Compartment P/N 94G7444.
7. Installation within a rack requires optional Netfinity Flat Panel Monitor Rack Mount Kit II P/N 37L6888 and Netfinity Rack
Keyboard Tray P/N 28L4707. A space saver keyboard may coexist within the same keyboard tray.
8. Rack Power Cable P/N 94G7448 (type C12 - one for each power supply), must be ordered for power connection to a high voltage
UPS or PDU.
9. Where ‘xx’ represents a specific country code: DK=Denmark, IS=Israel, IT=Italy, SD=Saudi Arabia, SA=South Africa,
CH=Switzerland, UK=UK, EU=Europe.
10. Where ‘xxx’ represents the appropriate country code as follows:- DEN=Denmark, ISR=Israel, ITA=Italy, SDI=Saudi Arabia,
SAF=South Africa, SWS=Switzerland, UKM=United Kingdom, EUR=Europe.
Part Number Description
Rack and NetBAY
1,8
930842P Netfinity Enterprise Rack
930842X Netfinity Enterprise Expansion Cabinet
9306900 Netfinity Rack
9306910 Netfinity Rack (includes perforated front door)
9306200 Netfinity NetBAY22
37L6888 Netfinity Flat Panel Monitor Rack Mount Kit II
94G7448 Rack Power Cable Type C12 (3.7m)
8
Keyboard and Mouse
2
28L36xx
6
Space Saver II Keyboard
3, 5
28L36xx
7
Preferred Keyboard (stealth black)
4
28L3675 Sleek 2-Button Stealth Black Mouse
1. xSeries 340 / Netfinity 4500R are housed in a 19” rack mountable drawer and requires one of the racks listed here. See IBM
Netfinity Rack Cabinet and Options section for IBM rack supported devices.
2. xSeries 340 / Netfinity 4500R ship without a keyboard or mouse.
3. Installation within a rack requires optional keyboard tray P/N 28L4707 (stows in “ready-to-use” position).
4. Installation within a rack requires optional keyboard tray P/N 28L4707. This keyboard cannot share a keyboard tray with a flat
panel display.
5. Advanced TrackPoint IV features are not available on IBM Netfinity systems.
6. Where ‘xx’ represents country specific code: 46=Danish , 47=France, 48=Germany, 49=Italian, 50=Spanish, 51=UK English,
44=US English, and P/N 19K3831=Switzerland, 19K3832=Sweden/Finland, 19K3833=Portugal, 19K3834=Belgium,
19K3836=Russia, 19K3837=Poland.
7. Where
‘xx’ represents a country specific code: 25=French, 26=German, 27=Italian, 29=English, 31=Danish, 33=Norwegian,
34=Swedish/Finnish, 35=Swiss, 36=Dutch.
8. The xSeries 340 / Netfinity 4500R ships with a standard country power cord. For connection to a high voltage UPS or PDU, a
Rack Power Cable P/N 94G7448 (type C12 - one for each power supply), must be ordered.
