55
Updated
28/02/01
Note: For a complete list of all IBM and non-IBM options compatibility with Network Operating Systems and IBM xSeries and Netfinity Servers,
access the IBM ServerProven compatibility pages on the Web at URL http://www.ibm.com/pc/us/compat
xSeries 340 / Netfinity 4500R Tape Options
Part
Number
Description Bays
Supported
SCSI
Interface
(bit)
Form
Factor
Termination
Included
68/50-pin
Converter Incl.
Ext. Tape
Enclosures
00N7991 20/40 GB DDS/4 4-mm Internal Tape Drive
2
A, B 16 Ultra2 LVD
89 mm
(3.5”) HH
or 133 mm
(5.25”) HH
N
3
N/A 03K8756
1
09N4040 20/40 GB DLT Internal SCSI Tape Drive A+B 8
133 mm
(5.25”) FH
N
3
Y 03K8756
00N7990 40/80 GB DLT Internal SCSI Tape Drive
2
A+B 16 Ultra2 LVD
133 mm
(5.25”) FH
N
3
N/A 03K8756
1
00N8017 60/120GB 8-mm M2 SCSI Tape Drive
2
A, B 16 Ultra2 LVD
133 mm
(5.25”) HH
N
3
N/A 03K8756
1
Tape Autoloaders
00N7992 120/240GB DDS/4 Tape Autoloader
2
A+B 16 Ultra2 LVD
133 mm
(5.25”) FH
N
3
N/A 03K8756
1
External Tape Libraries
4
00N79xx
7
DLT Tape Library - 16 Rack Y N/A -
External Tape Enclosures
03K8756 NetMEDIA Storage Expansion Unit EL
5
- 16 Rack Y N -
10L7113 NetMEDIA Systems Management Adapter
6
- 16 LVD - N N 03K8756
Associated Options
10K2340 Media Bay Tray and LVD Cable Kit
1,2
- 16 LVD Int. Y N 03K8756
Note: xSeries 340 / 4500R includes a single drop, 16-bit, single-ended, non-terminated SCSI cable for attachment of a device in Bay A or B to the second integrated Ultra160 SCSI channel or supported
adapter. No external SCSI port is available. All tape drives and enclosures are supported by PCI Wide Ultra160 SCSI Adapter (P/N 19K4646) which has an external 0.8-mm VHDCI connector.
1.LVD support for LVD devices installed in a NetMEDIA Storage Expansion Unit EL (P/N 03K8756) requires replacement of the standard single-ended internal cables with one or more (depending on
configuration) cables from Media Bay Tray and LVD Cable Kit (P/N 10K2340) which contains a single two-drop multi-mode LVD-SCSI terminated cable. If the standard cables are used for attachment to
LVD devices, single-ended SCSI rules and bus speeds apply.
2. LVD support for LVD devices requires installation of the 16-bit multi-mode terminated, two-drop, LVD SCSI cable included with optional Media Bay Tray and LVD Cable Kit (P/N 10K2340).
3. Termination requires installation of the multi-mode terminated, two-drop, LVD SCSI cable included with optional Media Bay Tray and LVD Cable Kit (P/N 10K2340)
4. Tape library attributes and prerequisites are located in Appendix B: Tape Library Attributes.
5. NetMEDIA Storage Expansion Unit EL (P/N 03K8756) is a black 3U, 19” rack-mountable tape enclosure which includes two full high (FH) or four half high (HH) extended length 133 mm (5.25”) bays,
two external 68-pin high density connectors and two internal four-drop single-ended terminated 16-bit SCSI cables for device attachment. Two power supplies and two power cords are also included. Tip: The
front rail clips will need to be reversed and screwed in from behind to secure the unit in a Rack Cabinet P/N 930842X.
6. NetMEDIA Systems Management Adapter (P/N 10L7113) may be installed in a NetMEDIA Storage Expansion Unit to provide repeater function, LVDS interface, aggregate cable lengths up to 12 meters
when attached to an LVD SCSI controller, and auto-termination when the Expansion Unit is powered off. External connector is 0.8-mm VHDCI.
7. Where ‘xx’ represents a country specific power cord code: Rack versions - 81=EU1, 82=Denmark, 83=India/South Africa, 84=UK, 85=Swiss, 86=Italy, 87=Israel.
Note: Additional tape details can be found in Appendix A: Tape Drive Attributes.
