To access IBM information specific to your country via the World Wide Web, use address: http://www.ibm.com/pc
Note: The following sample configurations are for illustration only and may not be suitable for any specific customer installation. Contact your IBM Business Partner or IBM
Marketing Representative for assistance with your specific configuration requirements.
Internet Server
An internet server handles all requests from the Internet (intranet or extranet). Usually this type of server has the same characteristics as a file server. The main difference is that an
internet server talks a different language (TCP/IP vs. NETBEUI or IPX/SPX) and often needs to do an extra security check (Firewall). In the case of an internet server, the server
itself talks mostly to just one client, the Internet Service Provider (ISP), instead of many clients as a file server does.
With this in mind the Netfinity 4500R was selected to provide an affordable price point for the growing internet server market, 256 MB of system memory (expandable to 4 GB), and
availability features such as RAID protected internal hot-swap storage and power protection with an APC Smart-UPS.
The network configuration depends on the method that will be used to connect the server to the internet. Usually fast Ethernet routers are used, but if other methods are used, you can
add the appropriate adapter. The configuration includes a tape backup unit for secure backup of critical data in the event of a system or storage failure.
Application Server
An application server is designed to handle a high workload while providing application serving requirements for users. With this in mind, the xSeries 340 was selected to provide an
affordable price point for an application server, with two-way Pentium III processing, 384 MB of system memory (expandable to 4GB),and availability features such as battery-
backed cache, RAID protected internal hot-swap storage and power protection with an APC Smart-UPS.
xSeries 340 / Netfinity 4500R Sample Configurations
Part Number Description Quantity
65RYTxx Netfinity 4500R 933MHz/256 KB, 128 MB ECC, OPEN, 24X, PCI 1
33L3123 128 MB SDRAM ECC RDIMM II 1
1
37L6080 ServeRAID-4M Ultra160 SCSI Controller 1
37L7201 9.1 GB Ultra160 SCSI Hot-Swap SL HDD 3
2
00N8017 60/120GB 8-mm M2 SCSI Tape Drive 1
10K2340 Media Bay Tray and LVD Cable Kit 1
T31U2xx E54 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black 1
14RIxxx APC Smart-UPS 1400RMB 1
37L6879 270 W Hot-Swap Redundant Power Supply 1
Industry Standard 19” Rack, EIA-310D, min. depth of 28” (711 mm)
9306200 Netfinity NetBAY22 1
28L36xx Space Saver II Keyboard 1
94G6670 Blank Filler Panel Kit 2
1. For a total of 256 MB of system memory.
2. Three HDDs are used for RAID 5 protection. Effective storage capacity is two HDDs or 18.2GB.
Part Number Description Quantity
K66RYxx xSeries 340 1GHz/256 KB, 128 MB ECC, OPEN, 24X, PCI 1
19K4630 1GHz Upgrade with 133 FSB and 256 KB Advanced Transfer Cache Pentium III Processor 1
33L3125 256 MB 133 MHz SDRAM ECC RDIMM II 1
1
37L6080 ServeRAID-4M Ultra160 SCSI Controller 1
37L7202 18.2 GB Ultra160 SCSI Hot-Swap SL HDD
2
3
2
00N8017 60/120GB 8-mm M2 SCSI Tape Drive 1
10K2340 Media Bay Tray and LVD Cable Kit 1
T31U2xx E54 Color Monitor 15” (350-mm, 13.8” Viewable Image Size), stealth black 1
37L6879 Netfinity 270 W Hot-Swap Redundant Power Supply 1
14RIxxx APC Smart-UPS 1400RMB 1
Industry Standard 19” Rack, EIA-310D, min. depth of 28” (711 mm)
9306200 Netfinity NetBAY22 1
28L36xx Space Saver II Keyboard 1
94G6670 Blank Filler Panel Kit 2
1. For a total of 384 MB of system memory.
2. Three HDDs are used for RAID 5 protection. Effective storage capacity is two HDDs or 36.4GB.
