60
Updated
28/02/01
To access IBM information specific to your country via the World Wide Web, use address: http://www.ibm.com/pc
Internal SCSI Cabling
The Netfinity 6000R contains a DASD backplane supporting three hot-swap, SCA-2 compliant drive bays. The backplane is connected to one of the internal connectors of the
integrated dual-channel Ultra160 SCSI controller through a 16-bit LVD SCSI cable. An optional Netfinity 3-Pack Ultra160 Hot-Swap Expansion Kit
(P/N 33L5050) can be installed to provide additional internal HDD storage capacity. Within this option are two 16-bit LVD SCSI cables. One can be attached from the 3-Pack Ultra
Hot-Swap backplane to the second connector of the dual-channel Ultra160 SCSI controller, the other, through the use of a repeater card included with the option, can be cabled
directly to the standard backplane.
In configurations where external SCSI device attachment is required instead of additional internal HDD storage, a second 16-bit LVD SCSI cable is included with the server. One
end of the cable can be attached to the second Ultra160 connector and the other is attached to the external 0.8-mm VHDCI connector on the back of the chassis. This provides an
external connection to support LVDS devices.
Bay Form Factor Height Front
Access
Usage Part
Number
Description RPM Height Bays
Supported
2
Max.
Qty.
-
89 mm
(3.5”)
SL Yes Diskette
Ultra160 Hard Disk Drives (HDD)
- 133 mm (5.25”) HH Yes
IDE CD-
ROM
37L7201 9.1 GB Ultra160 SCSI Hot-Swap HDD 7200 SL 1...6 6
1
1...3 HS SL
1
Yes Open 37L7202 18.2 GB Ultra160 SCSI Hot-Swap HDD 7200 SL 1...6 6
1
4...6
2
HS SL
1
Yes Open 37L7203 36.4 GB Ultra160 SCSI Hot-Swap HDD 7200 SL 1...6 6
1
1. Half-high (HH) devices are NOT supported.
2. To enable Bays 4...6, optional Netfinity 3-Pack Utra160 Hot-Swap Expansion Kit
P/N 33L5050 is required.
37L7204
9.1 GB 10K-4 Ultra160 SCSI Hot-Swap
HDD
10,000 SL 1...6 6
1
37L7205
18.2 GB 10K-4 Ultra160 SCSI Hot-Swap
HDD
10,000 SL 1...6 6
1
37L7206
36.4 GB 10K-4 Ultra160 SCSI Hot-Swap
HDD
10,000 SL 1...6 6
1
19K0655
9.1 GB 15K-rpm Ultra160 SCSI Hot-Swap
HDD
15000 SL 1...6 6
1
19K0656
18.2 GB 15K-rpm Ultra160 SCSI Hot-
Swap HDD
15000 SL 1...6 6
1
Associated Options
33L5050
Netfinity 3-Pack Ultra160 Hot-Swap
Expansion Kit
1, 2
- 3 x SL 4...6 -
External Storage Expansion Units
3
Form Factor
19K11xx
9
EXP300 Storage Expansion Unit
4, 8
Rack (3U)
19K11xx
10
FAStT 200 Storage Server
5, 6, 8
Rack (3U)
19K11xx
11
FAStT 200 HA Storage Server
5, 8
Rack (3U)
19K1121 FAStT 200 Redundant RAID Controller
6
-
00N71xx
12
FAStT EXP500 Storage Expansion Unit
7, 8
Rack (3U)
94G7448 Rack Power Cable Type C12 (3.7m, 12 ft.)
8
-
1. Netfinity 6000R ships with bays 1...3 enabled. To enable installation of greater than three HDDs requires Netfinity 3-
Pack Ultra160 Hot-Swap Expansion Kit P/N 33L5050.
2. Netfinity 3-Pack Ultra160 Hot-Swap Expansion Kit P/N 33L5050 is required to enable bays 4 to 6. It includes a hot-
swap backplane and associated components for two cabling options. Within the option are two 16-bit LVD SCSI cables.
One can be attached from the 3-pack Ultra160 Hot-Swap backplane to the second connector of the dual-channel Ultra160
SCSI controller, the other, through the use of a repeater card included with the option, can be cabled directly to the
standard backplane. Utilising the second channel will eliminate the possibility of attaching external devices to that
channel.
3. Not supported by the onboard external SCSI port. Select an optional SCSI controller then refer to Appendix D: Cables-
Storage Units-Controllers to confirm the controller supports the desired External Storage Expansion Unit and to select a
supported cable. For HDD or other expansion unit options, see the specific expansion unit section.
4. The EXP300 includes a single 2 M Ultra2 SCSI cable and dual hot-swap 500W redundant power supplies, each with
it’s own standard country power cord.
5. The FAStT200 Storage Server and HA Storage Server each include two hot-swap, 350 W auto-ranging redundant
power supplies each with it’s own standard country power cord.
6. Can be upgraded to a FAStT200 HA Storage Server through the addition of a FAStT200 Redundant RAID Controller
P/N 19K1121.
7. The FAStT EXP500 Storage Expansion Unit includes dual hot-swap 350W power supplies, each with it’s own
standard country power cord.
8. These units do not include Rack Power Cables P/N 94G7448 when shipped (for attachment to high voltage UPS or
PDU). Standard country power cords only are included. If required, order Rack Power Cables according to the number of
power supplies.
9.Where ‘xx’ represents a specific country code as follows: 51=US/English, 52=European/English, 56=Danish/English,
57=Israel/English, 58=Italian/English, 59=South Africa/English, 60=Swiss/English, 63=UK/English:- Line Cords/
Publication Country Kits are included as indicated.
10. Where ‘xx’ represents a country specific code as follows:- 23=US/English, 24=Euro/English, 25=Euro/Spanish,
27=Euro/German, 28=Denmark/English, 29=Israel/English, 30=Italy/English, 31=South Africa/English,
32=Switzerland/English, 34=Switzerland/German, 36=UK/English. Country/Language - Line Cords/Publications are
included as indicated
11. Where ‘xx’ represents a country specific code as follows:- 37=US/English, 38=Euro/English, 39=Euro/Spanish,
41=Euro/German, 42=Denmark/English, 43=Israel/English, 44=Italy/English, 45=South Africa/English,
46=Switzerland/English, 48=Switzerland/German, 50=UK/English. Country/Language - Line Cords/Publications are
included as indicated.
12. Where ‘xx’ represents a country specific code as follows:- 36=US/English, 37=Euro/English, 41=Denmark/English,
42=Israel/English, 43=Italy/English, 44=South Africa/English, 45=Switzerland/English, 49=UK/English. Country/
Language Line Cords/Publications are included as indicated.
Diskette
Bay 1
CD-ROM
Bay 2
To enable Bays 4...6, optional Netfinity 3-Pack Ultra160 Hot-
Swap Expansion Kit (P/N 33L5050) is required.
Bay 3
Bay 4
Bay 5
Bay 6
