IBM eServer xSeries User Manual

61
Updated
28/02/01
Netfinity 6000R I/O Options
Part
Number
Description Adapter
Length
PCI
Support
Slots
Supported
1
Hot-
Plug
2
PCI Voltage
Key
MHz
SCSI Storage Controllers
3
37L6091 ServeRAID-4L Ultra160 SCSI Controller
5
Full 32/64-bit 1...6
4
X Universal 33
37L6080 ServeRAID-4M Ultra160 SCSI Controller
6
Full 32/64-bit 1...6
4
X Universal 33
37L6889 ServeRAID-4H Ultra160 SCSI Controller
7
Full 32/64-bit 1...6
4
X Universal 33
02K3454 PCI Fast/Wide Ultra SCSI Adapter Half 32-bit 1, 5, 6 - 5 33
19K4646 PCI Wide Ultra160 SCSI Adapter
8
Half 32/64-bit 1...6 - Universal 66
Fibre Storage Controller
9
00N6881 Netfinity FAStT Host Adapter Half 32/64-bit 1...6 X Universal 66
Networking
10
Ethernet
09N9901 Netfinity 10/100 EtherLink Server Adapter by 3Com Half 32-bit 1...6
4
X Universal 33
34L1501 Netfinity 10/100 Ethernet PCI Adapter 2 Half 32-bit 1...6
4
X Universal 33
19K4401 Netfinity Gigabit Ethernet Adapter Half 32/64-bit 1...6
4
X Universal 33
06P3601 10/100 Ethernet Server Adapter Half 32-bit 1...6
4
X Universal 33
06P3701 Gigabit Ethernet SX Server Adapter (fibre optic cabling interface) Half 32/64-bit 1...6 X Universal 66
Token Ring
34L0701 Token-Ring 16/4 PCI Adapter 2 with Wake on LAN
11
Half 32-bit 1...6
4
X Universal 33
34L5201 High-Speed 100/16/4 Token-Ring PCI Management Adapter
11
Half 32-bit 1...6
4
X Universal 33
Communications
12
37L14xx Serial I/O SST 8, 16, and 128 port adapters
13
Half 32-bit 1, 5, 6
13
- 5 33
Systems Management
14
36L96xx
19
Netfinity Advanced System Management PCI Adapter
15, 16
Full 32-bit 1, 5, 6
16
- 5 33
03K9309 Netfinity Advanced System Management Interconnect Cable Kit
17
-- ----
36L9654 Netfinity Advanced System Management Token-RIng Connection
18
- - - - - -
1.The 5 V - 33 MHz slots support Universal or 5 V adapters. A universal voltage-66 MHz adapter plugged into these slots will operate at 33 MHz.The 3.3 V slots support universal or 3.3 V adapters. A
universal voltage-33 MHz adapter plugged into these slots limits a 66 MHz PCI adapter installed on the same bus to 33 MHz.
2. All six slots are full length hot-plug capable using IBM’s Active PCI technology. For Network Operating System support access URL www.ibm.com/pc/us/compat
3. Netfinity 6000R includes a dual-port, dual-channel Ultra160 SCSI controller. See “Internal SCSI Cabling” for cabling alternatives.
4. Installation of a 33 MHz adapter into a Bus B 66 MHz slot will slow operation of all Bus B slots to 33 MHz.
5. Netfinity ServeRAID-4L Ultra160 SCSI controller is powered by a 100 MHz Intel i960 processor and provides a single channel, 16 MB of ECC cache and either one internal or one external Ultra160
connection. External connector is 0.8-mm VHDCI.
6. Netfinity ServeRAID-4M Ultra160 SCSI controller is powered by a 100MHz Intel i960 processor and provides two channels, 64 MB of battery-backed ECC cache and two internal and two external
Ultra160 connectors (only two connectors may be utilized). External connectors are 0.8-mm VHDCI.
7. Netfinity ServeRAID-4H Ultra160 SCSI controller is powered by a 266MHz PowerPC 750 processor and provides 128 MB of battery-backed ECC cache with two internal and up to four external Ultra160
connectors (only four connectors may be utilized). External connectors are 0.8-mm VHDCI.
8. PCI Wide Ultra160 SCSI Adapter (P/N 19K4646) provides a single channel with one internal connector and a five-drop multi-mode terminated LVD SCSI cable and one external connector with a 0.8-mm
VHDCI connector. Only one of the two connectors may be utilised.
9. See Fibre Array Solutions section for additional configuration information.
10. Netfinity 6000R has an integrated 10/100 PCI Ethernet Controller.
11. The Wake on LAN function of this option is not supported by this server.
12. Netfinity 6000R includes two USB ports, two serial and one parallel port.
13. See Appendix E for details on Serial I/O options and configuration limitations. A maximum of four Serial I/O adapters (in any combination) may be installed.
14. The Netfinity Advanced Systems Management Processor and Interconnect Bus integrated into Netfinity 6000R works with Netfinity Director to provide significant system management function. When
used with optional Netfinity Advanced System Management PCI Adapter P/N 36L96xx and Netfinity Advanced System Management Interconnect Cable Kit P/N 03K9309 additional management and
control of up to 12 service processors from a remote console through a single modem or LAN connection is possible.
15. Includes PCI adapter, Netfinity Advanced System Management Interconnect Cable Kit components and 56-watt AC adapter which requires a separate power source. Provides an integrated 10/100
Ethernet port and PCMCIA slot to support optional Netfinity Advanced System Management Token-Ring Connection P/N 36L9654.
16. A maximum quantity of one is supported.
17. Required for all xSeries and Netfinity servers containing a standard Advanced System Management Processor that are to be interconnected for system management support through a LAN or modem
connection (Netfinity 5500 models 1xX to 4xX are not supported). Up to 12 service processors may be interconnected (including standard and optional processors) with an aggregate connection length of no
more than 91.4 meters (300 ft.). A customer-supplied Ethernet cable is required for each interconnection.
18. Contains an IBM Turbo 16/4 Token-Ring PCI Card, which installs in the PCMCIA card slot of Netfinity Advanced System Management PCI Adapter, and a PC Card to 9-pin D-Shell cable which is
routed to an available adapter slot opening (reduces available slots by one). The Netfinity Advanced System Management PCI Adapter’s integrated Ethernet port and Netfinity Advanced System
Management Token-Ring Connection cannot be connected or used together.
19. Where ‘xx’ represents a country specific code: 57=Denmark, 58=South Africa/India, 59=UK, 60=Switzerland, 61=Italy, 62=Israel, 01K7310=Europe, 01K7209=US/Saudi Arabia.
