64
Updated
28/02/01
To access IBM information specific to your country via the World Wide Web, use address: http://www.ibm.com/pc
Note: The following sample configurations are for illustration only and may not be suitable for any specific customer installation. Contact your IBM Business Partner or IBM
Marketing Representative for assistance with your specific configuration requirements.
Internet Server
An Internet server handles all requests from the Internet (intranet or extranet). Usually, this type of server has the same characteristics as a file server. The main difference is that an
internet server talks a different language (TCP/IP vs. NETBEUI or IPX/SPX) and often needs to do an extra security check (firewall). In the case of an Internet server, the server
itself talks mostly to just one client, the Internet Service Provider (ISP), instead of many clients as a file server does.
With this in mind, the IBM Netfinity 6000R was selected to provide an affordable price point for the growing internet server market, 512MB of system memory (expandable to
16GB), and availability features such as RAID protected internal hot-swap storage and power protection with an APC Smart-UPS.
The network configuration depends on the method that will be used to connect the server to the Internet. Usually fast Ethernet routers are used, but if other methods are used, you can
add the appropriate adapter. The configuration includes a tape backup unit for secure backup of critical data in the event of a system or storage failure.
Application Server
An application server is designed to handle a high workload while providing application serving requirements for users. With this in mind, the IBM Netfinity 6000R was selected to
provide an affordable price point for an application server, with four-way Pentium III Xeon processing, 2 GB of system memory (expandable to 16 GB), and availability features
such as battery-backed cache RAID protected internal hot-swap storage and power protection with an APC Smart-UPS.
Netfinity 6000R Sample Configurations
Part Number Description Quantity
21RYMxx Netfinity 6000R 700/1MB Xeon, 512MB ECC, Open, 40X, PCI 1
37L6091 ServeRAID-4L Ultra160 SCSI Controller 1
33L5050 Netfinity 3-Pack Ultra160 Hot-Swap Expansion Kit 1
37L7201 9.1GB Ultra160 SCSI Hot-Swap SL HDD 4
1
00N8017 20/40GB 8mm Internal SCSI Tape Drive 1
10K2340 Media Bay Tray and LVD Cable Kit 1
03K8756 NetMEDIA Storage Expansion Unit EL 1
03K9310 Netfinity 2M Ultra2 SCSI Cable 1
T31U2xx E54 Color Monitor 15” (350mm, 13.8” Viewable Image Size), stealth black 1
14RIxxx APC Smart-UPS 1400RMB 1
Industry Standard 19” Rack, EIA-310D, min. depth of 28” (711 mm)
9306200 Netfinity NetBAY22 1
28L36xx Space Saver II Keyboard 1
94G6670 Blank Filler Panel Kit 2
1. Four HDDs are used for RAID 5 protection. One HDD is identified as a hot-spare. Effective storage capacity is two HDDs or 18.2GB
Part Number Description Quantity
22RYMxx Netfinity 6000R 700/2 MB Xeon, 512 MB ECC, Open, 40X, PCI 1
00N7944 700 MHz/2 MB Upgrade with Pentium III Xeon Processor 3
33L3113 Netfinity 128 MB, 100 MHz ECC SDRAM RDIMM 4
1
33L3115 Netfinity 256 MB, 100 MHz ECC SDRAM RDIMM 4
1
33L5050 Netfinity 3-Pack Ultra160 Hot-Swap Expansion Kit 1
37L7203 36.4 GB Ultra160 SCSI Hot-Swap SL HDD 4
2
37L6080 ServeRAID-4M Ultra160 SCSI Controller 1
00N7990 40/80 GB DLT Internal SCSI Tape Drive 1
10K2340 Media Bay Tray and LVD Cable Kit 1
03K8756 NetMEDIA Storage Expansion Unit EL 1
10L7113 NetMEDIA Systems Management Adapter 1
03K9310 Netfinity 2 M Ultra2 SCSI Cable 1
T31U2xx E54 Color Monitor 15” (350 mm, 13.8” Viewable Image Size), stealth black 1
14RIxxx APC Smart-UPS 1400RMB 1
37L6879 270 W Hot-Swap Redundant Power Supply 2
Industry Standard 19” Rack, EIA-310D, min. depth of 28” (711 mm)
9306200 Netfinity NetBAY22 1
28L36xx Space Saver II Keyboard 1
94G6670 Blank Filler Panel Kit 2
1. For a total of 2 GB of system memory.
2. Four HDDs are used for RAID 5 protection. Effective storage capacity is three HDDs or 109.2GB
