Removing Adapters
1. If you have not already done so, remove the covers as described in “Removing
Both the Front and Side Covers” on page 5-10
2. Remove the I/O planar cover as described in “Removing the I/O Planar Cover”
on page 5-16; then return here to determine your next step.
3. Remove any cables that are attached to the adapter.
4. Remove the adapter:
a. Note the slot number of the adapter you are removing.
b. If there are any cables attached to the adapter, disconnect them.
c. Remove the screw for the adapter.
5-34 IBM RS/6000 7025 F50 Series User's Guide
