• At least three persons are required to move the enclosure while it is in the rack (if you are moving the
enclosure off the rails). Even after the drives, power supply units, secondary expander modules,
canisters, fans, and top cover are removed, the enclosure weighs approximately 43 kg (95 lbs).
• To maximize rack stability, always install the expansion enclosure in the lowest possible position in the
rack.
Weight of expansion enclosure parts
Table 24 on page 32 summarizes the weight and quantity of the parts (FRUs) that are shipped with the
5U expansion enclosure.
Table 24. Weight of expansion enclosure parts
FRU description
Weight per unit
Quantity
shipped
Total weight
kg lbs kg lb
Enclosure FRU 42.5 93.696 1 42.500 93.696
Rail kit 9.231 20.351 1 9.231 20.351
Front fascia (4U front cover) 0.303 0.668 1 0.303 0.668
Display panel assembly 0.020 0.044 1 0.020 0.044
PSU fascia (1U cover) 0.010 0.022 1 0.010 0.022
Power supply unit (PSU) 3.335 7.352 2 6.670 14.705
Secondary expansion module 0.826 1.821 2 1.652 3.642
Fan module 0.890 1.962 4 3.560 7.848
Expansion canister 1.588 3.501 2 3.176 7.002
Cable management arm
(lower and upper arms)
1.373 3.027 1 1.373 3.027
Top cover 3.720 8.201 1 3.720 8.201
Fan interface board 0.118 0.260 1 0.236 0.260
Weight of expansion enclosure SAS drives
The SAS drives are shipped in a separate package from the 5U expansion enclosure. The enclosure can
support up to 92 SAS drives; however, the quantity varies depending on the number of drives ordered.
Table 25 on page 32 summarizes the weight of the drives that are supported in the 5U expansion
enclosure.
Table 25. Weight of expansion enclosure drives
FRU description
Approximate weight per unit
kg lb
1.6 TB 2.5-inch tier 0 flash drive 0.224 0.494
3.2 TB 2.5-inch tier 0 flash drive 0.224 0.494
1.92 TB 2.5-inch tier 1 flash drive 0.224 0.494
3.84 TB 2.5-inch tier 1 flash drive 0.224 0.494
7.68 TB 2.5-inch tier 1 flash drive 0.224 0.494
15.36 TB 2.5-inch tier 1 flash drive 0.224 0.494
32 IBM FlashSystem 5000 : FlashSystem 5000 Quick Installation Guide
