IBM iSeries 820 Service Manual

Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and replace or
recovery procedure
C10 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
C11 PCI card The failing component
is either an:
1. IOP
2. Integrated xSeries
Server (IXS)
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. 2890 (See page 527) or
2892 (See page 527)
Note: When the IXS
card is installed in this
position, concurrent
maintenance at the
card position is not
recommended.
If IXS, go to Models 830/SB2 with
FC 9074 - Cards (dedicated).
Otherwise, go to Models 830/SB2
with FC 9074 - Cards
(concurrent).
C12 PCI card (if
no IXS in
C11)
The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
C13 PCI card
(Short if 2890
IXS in C11)
IOA See the Type, model, and
part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
C14 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
C15 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
CB1 Tower card
v SPCN card
v Tower card
v Service processor
v Multi-adapter
bridge (all)
28AA (See page 527) Go to Models 830/SB2 with FC
9074 - Tower card (CB1).
B01 and
B02
AMD AMD 04N3345 Go to FC 5074/5079, FC 9074,
FC 9079 - AMD - B01 and B02.
A01 AC input /
charger
AC module / charger 97H7316 - Single line cord Go to Models 830/SB2 with FC
9074 (with single line cord) - AC
input/charger (A01).
Analyze hardware problems 265
