IBM iSeries 820 Service Manual

Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and replace or
recovery procedure
C03 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
C04 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
C05 PCI card The failing component
is either an:
1. IOP
2. Integrated xSeries
Server (IXS)
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. 2890 (See page 527) or
2892 (See page 527)
Note: When the IXS
card is installed in this
position, concurrent
maintenance at the
card position is not
recommended.
If IXS, go to Models 830/SB2 with
FC 9074 - Cards (dedicated).
Otherwise, go to Models 830/SB2
with FC 9074 - Cards
(concurrent).
C06 PCI card (if
no IXS in
C05)
The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
C07 PCI card
(Short if 2890
IXS in C05)
IOA See the Type, model, and
part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
C08 HSL I/O
bridge card
1. High-speed link
I/O bridge
2. PCI host bridge
v 2681 (See page 524)
v See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
C08 ports HSL ports See Figure 6. Models
830, SB2 with FC
9074 - HSL and
SPCN locations (See
page 269) below.
N/A N/A
C09 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
Go to Models 830/SB2 with FC
9074 - Cards (concurrent).
264 Hardware (Remove and Replace; Part Locations and Listings)
