Position FRU name
Possible failing
component
Type, CCIN, or part
number (use the Type,
model, and part number
list to determine the part
number when the type or
CCIN are given.)
Remove and replace or
recovery procedure
M05
(daughter
cards)
Memory
DIMM
See Figure 3. CCIN
2881 with pluggable
DIMM (See page 267)
below.
300F (See page 528), 3002
(See page 528), 3004 (See
page 528), 3005 (See page
528), or 3006 (See page
528)
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
M06 Network
Interface
Controller
(NIC) Card
Network Interface
Controller (NIC)
2732 (See page 524), 2754
(See page 525), or 2758
(See page 525).
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
M06 ports Network
Interface
Controller
(NIC) Ports
See Figure 4.
Network Interface
Controller (NIC) port
locations (See page
268) below.
N/A N/A
M06A Clock card Clock card 25AB (See page 523) for
systems with processor
feature codes 23C1, 23C2,
23C3, 23C4, and 23C5
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
M06A Clock card Clock card 25AD (See page 523) for
systems with processor
feature codes 23D1, 23D2,
23D3, 23D4, 23D5, 23D6,
23D8, 23D9, 23DA, 23DB,
23DC, 23DD, 23DE, 26A8,
26A9, 26AA, 26AB, 26AC,
26AD, and 26AE
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
M06-C08 HSL ribbon
cable
HSL connection
(SIGC73), See “Model
830 and SB2 with FC
9074” on page 492 in
the Power and signal
cables page.
See the “Model 830 and
SB2 with FC 9074” on
page 492 in the Power and
signal cables page.
N/A
PP1 and
PP2
Power supply Power supply 515B (See page 530) Go to Models 830/SB2 with FC
9074 - Power supply (PP1 and
PP2).
BP1 and
BP2
Air moving
device (AMD)
AMD 04N3345 Go to Models 830/SB2 with FC
9074 - Air moving device - BP1
and BP2
C01 PCI card IOP 2842 (See page 527), 2843
(See page 527), or 2844
(See page 527)
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
C02 PCI card The failing component
is either an:
1. IOP
2. IOA
1. 2842 (See page 527),
2843 (See page 527),
or 2844 (See page 527)
2. See the Type, model,
and part number list.
.
Go to Models 830/SB2 with FC
9074 - Cards (dedicated).
Analyze hardware problems 263
