49 1621811 2 Screw, M4 (10mm)
50 44H8641 2 Cable Clamp, To p
51 44H8640 2 Cable Clamp, Base
52 1621811 2 Screw, M4 (10mm)
Figure 7. Final assembly — FC 5074 (single line cord)
Table 7. Final assembly — FC 5074 (single line cord)
Index Part number Units Description
53 53P4651 1 Power sub frame assembly
54 1621811 12 Screw, M4 (10mm)
55 97H7318 1 Battery pack - This part
number includes four
batteries. Refer to the
BATRY symbolic FRU for
additional information.
56 1621811 12 Screw, M4 (10mm)
57 24L0940 AR Filler, Spacer
58 1621811 2 Screw, M4 (10mm)
Analyze hardware problems 463
