Index Part number Units Description
59 NONUM 1 EMC access plate
60 1621811 2 Screw, M4 (10mm)
61 24L0939 AR Filler, power supply
62 1621811 2 Screw, M4 (10mm)
63 44H8641 2 Cable Clamp, To p
64 44H8640 2 Cable Clamp, Base
65 1621811 2 Screw, M4 (10mm)
66 97H7316 1 Battery charger
67 1621811 4 Screw, M4 (10mm)
68 90H6629 3 Power supply — 765 watts
(P01, P02, P03)
Final assembly — FC 5075: For use by authorized service providers.
Figure 1. Final assembly — FC 5075
464 Hardware (Remove and Replace; Part Locations and Listings)
