Name Description Part number
PWR61 to PWR64 Power distribution board (PB1) to Device board 3 (DB3) 97H7483
PWR65 Power distribution board (PB1) to Device board 2 (DB2) 97H7544
PWR66 to PWR69 Power distribution board (PB1) to Device board 2 (DB2) 97H7543
PWR70 Power distribution board (PB1) to Device board 1 (DB1) 97H7544
PWR71 to PWR74 Power distribution board (PB1) to Device board 1 (DB1) 97H7543
PWR75 Power distribution board (PB1) to AMDs (B01 and B02) 97H7475
PWR77 AC Input (A01) to Power supply 1 (P01 and P03) 04N2181
PWR78 AC Input (A02) to Power supply 2 (P00 and P02) 04N2181
Table 26. Model 840 and Model SB3 (FC 9079) Base I/O Tower - Signal cables - dual line cord
Name Description Part number
SIG60 Tower card (CB1) to Device board 3
(DB3)
97H7481
SIG61 Tower card (CB1) to Device board 2
(DB2)
44L0070
SIG62 Tower card (CB1) to Device board 1
(DB1)
97H7484
SIG63 Control panel (NB1) to Device board
3 (DB3)
24L1752
SIG64 Tower card (CB1) to Power
distribution board (PB1) (Includes P/N
97H7476, 97H7477, 97H7607) (part
of Tower card FRU assembly)
24L0843
SIGC65 JTAG A (internal to TWRCARD) 41L5946
SIGC66 V/S COMM (internal to TWRCARD) 44L0007
SIGC67 JTAG C/E (internal to TWRCARD) 24L0881
Models 870 and 890 processor towers: There are two tables covered here:
v Power cables (See page 506)
v AC line cords (See page 510)
Models 870 and 890 Power cables
Use the diagram and table below for information on the power cables for the Models 870 and 890.
Figure 14. Models 870 and 890 - Power cables
506 Hardware (Remove and Replace; Part Locations and Listings)
