IBM Motherboard - PC Health Status Page

35
Chapter 3: BIOS Setup Utility
PC Health Status Page
On motherboards that support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Shutdown Temperature (Disabled)
Enables you to set the maximum temperature the system can reach before powering
down.
System Component Characteristics
These fields provide you with information about the systems current operating
status. You cannot make changes to these fields.
• CPU Vcore
• VDIMM
• CPU Temperature
• SYSEM Temperature
• CPU FAN SPEED
• SYSTEM FAN SPEED
Phonex-AwardBIOS CMOS Setup Utility
PC Health Status
Help Item
Menu Level
f
Shutdown Temperature [80
o
C/176
o
F]
CPU Vcore 1.08V
VDIMM 1.80V
CPU Temperature 49
o
C
SYSTEM Temperature 44
o
C
CPU FAN SPEED 6250 RPM
SYSTEM FAN SPEED 0 RPM
: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help
F5: Previous Values F6: Fial-Safe Defaults F7: Optimized Defaults
