3
Chapter 1: Introduction
Onboard I/O Ports
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port
• One VGA port
• Four back-panel USB2.0 ports
• One LAN port (Optional)
• Audio jacks for microphone, line-in and line-out
Fast Ethernet LAN (Optional)
• Built-in 100Base-TX/10Base-T Physical Layer solution
• Dual Speed -- 100/10 Mbps
• MII Interface to Ethernet Controller and Configuration & Status
• Auto Negotiation: 10/100, Full/Half Duplex
• Meet All applicable IEEE 802.3/802.3u, 10Base-T and 100 Base-TX Stan-
dards
USB 2.0
• Compliant with Universal Serial Bus Specification Revision 2.0
• Compliant with Intel Enhanced Host Controller Interface Specification
Revision 1.0
• Compliant with Universal Host Controller Interface Specification Revision
1.1
• Support PCI-Bus Power Management Interface Specification release 1.1
• Legacy support for all downstream facing ports
BIOS Firmware
This motherboard uses Award BIOS that enables users to configure many system
features including the following:
• Power management
• Wake-up alarms
• CPU parameters and memory timing
• CPU and memory timing
The firmware can also be used to set parameters for different processor clock
speeds.
Dimensions
• Micro ATX form factor of 228 x 190 mm
Note: Hardware specifications and software items are subject to change
without notification.
