9
11
10b
12
9
d
10a
Note: Step 9 is only for the models with the Bluetooth
wireless features. For the other models, skip this
step.
Step Screw (quantity) Color Torque
9 M2 × 4 mm, bind-head,
nylon-coated (2)
Black 0.245 Nm
(2.5
kgfcm)
Remove the hinges 10a, 10b and the wireless LAN
antenna cables 11, 12
(continued)
Removing and replacing a FRU
ThinkPad T43 Series 173
