4405ch01 General description.fm Draft Document for Review May 22, 2009 3:10 pm
18 IBM Power 570 Technical Overview and Introduction
򐂰 When a system is installed in an 7014-T00 or -T42 rack that has no front door, a Thin
Profile Front Trim Kit must be ordered for the rack. The required trim kit for the 7014-T00
rack is FC 6246. The required trim kit for the 7014-T42 rack is FC 6247.
򐂰 The design of the 570 is optimized for use in a 7014-T00 or -T42 rack. Both the front cover
and the processor flex cables occupy space on the front left side of an IBM 7014 rack that
may not be available in typical non-IBM racks.
򐂰 Acoustic Door features are available with the 7014-T00 and 7014-T42 racks to meet the
lower acoustic levels identified in the specification section of this document. The Acoustic
Door feature can be ordered on new T00 and T42 racks or ordered for the T00 and T42
racks that clients already own.
1.4.6 Useful rack additions
This section highlights useful additions to a rack.
IBM 7214 Model 1U2 SAS Storage Enclosure
IBM 7212 Model 102 IBM TotalStorage storage device enclosure
The IBM 7212 Model 102 is designed to provide efficient and convenient storage expansion
capabilities for selected System p servers. The IBM 7212 Model 102 is a 1 U rack-mountable
option to be installed in a standard 19-inch rack using an optional rack-mount hardware
feature kit. The 7212 Model 102 has two bays that can accommodate any of the following
storage drive features:
򐂰 A Digital Data Storage (DDS) Gen 5 DAT72 Tape Drive provides a physical storage
capacity of 36 GB (72 GB with 2:1 compression) per data cartridge.
򐂰 A VXA-2 Tape Drive provides a media capacity of up to 80 GB (160 GB with 2:1
compression) physical data storage capacity per cartridge.
򐂰 A Digital Data Storage (DDS-4) tape drive provides 20 GB native data capacity per tape
cartridge and a native physical data transfer rate of up to 3 MBps that uses a 2:1
compression so that a single tape cartridge can store up to 40 GB of data.
򐂰 A DVD-ROM drive is a 5 1/4-inch, half-high device. It can read 640 MB CD-ROM and
4.7 GB DVD-RAM media. It can be used for alternate IPL
3
(IBM-distributed CD-ROM
media only) and program distribution.
򐂰 A DVD-RAM drive with up to 2.7 MBps throughput. Using 3:1 compression, a single disk
can store up to 28 GB of data. Supported DVD disk native capacities on a single
DVD-RAM disk are as follows: up to 2.6 GB, 4.7 GB, 5.2 GB, and 9.4 GB.
Flat panel display options
The IBM 7316-TF3 Flat Panel Console Kit can be installed in the system rack. This 1 U
console uses a 15-inch thin film transistor (TFT) LCD with a viewable area of
304.1 mm x 228.1 mm and a 1024 x 768 pels
4
resolution. The 7316-TF3 Flat Panel Console
Kit has the following attributes:
򐂰 Flat panel color monitor
򐂰 Rack tray for keyboard, monitor, and optional VGA switch with mounting brackets
򐂰 IBM Travel Keyboard mounts in the rack keyboard tray (Integrated Trackpoint and
UltraNav)
3
Initial program load
4
Picture elements
