Product characteristics
Safety:
v UL CD certified to EN60950 3rd Edition
v CSA C22.2 No 60950
v UL recognized to UL60950 3rd Edition
Physical characteristics:
v Physical Dimensions: (16.8in./42.7cm)x(6.6in./16.76cm)x(1.6in./4.06cm)
v Weight: 7.05 lb./3.2 kg
Environmental Limits:
v Operating
– Temperature:0-40C(ambient air temperature)
– Humidity: 5 - 95% (noncondensing)
– Wet Bulb: 29 C
– Altitude: 0 - 7000 ft
v Storage
– Temperature:1-60C
– Humidity: 5 - 80% (non-condensing)
– Wet Bulb: 29 C
v Shipping
– Temperature: -40 to 60 C
– Humidity: 5 - 100% (non-condensing)
– Wet Bulb: 29 C
Power Consumption
Table 68. 7036-P16 power consumption
Voltage (input) Current (amp) Watt
100 - 250 VAC nominal 0.8 A Maximum 12 W typical
90 - 264 VAC maximum 40A in rush
47/63 Hz 2A fuse
Throughput considerations
The limits on throughput are a function of the network and the server or server partition to which the
7036-P16 ports are configured.
System port throughput:
The 7036-P16 supports full-duplex operation up to 230 kbps on all ports. Operation with all 16 ports
running full-duplex at 230 kbps is supported.
Network throughput:
The 7036-P16 is an Ethernet attached device and as such, any number may be attached to a given
network. However, attaching more devices to any network reduces the overall network throughput and
care must be taken to not overload any given network.
94 Managing devices
