Figure 63. Removing the control panel from the bracket for a rack-mounted system
5. For the rack-mounted system, remove the screws (A) that secures the bracket (B) to the side of the
system as shown in Figure 64 on page 68 and remove the bracket.
Control panel cables for the 9009-41A, 9009-42A, or 9223-42H
67
