Table 30. Bulk power assembly (BPA) locations and failing components (continued)
Failing item name Physical location code
PCIe riser8 Un-P1-C8
PCIe8 Un-P1-C8-C1
PCIe riser9 Un-P1-C9
PCIe9 Un-P1-C9-C1
PCIe riser10 Un-P1-C10
PCIe10 Un-P1-C10-C1
PCIe riser11 Un-P1-C11
PCIe11 Un-P1-C11-C1
PCIe riser12 Un-P1-C12
PCIe12 Un-P1-C12-C1
PCIe riser13 Un-P1-C13
PCIe13 Un-P1-C13-C1
PCIe riser14 Un-P1-C14
PCIe14 Un-P1-C14-C1
PCIe riser15 Un-P1-C15
PCIe15 Un-P1-C15-C1
PCIe riser16 Un-P1-C16
PCIe16 Un-P1-C16-C1
PCIe riser17 Un-P1-C17
PCIe17 Un-P1-C17-C1
L-Link
48 Cable L-Link Connector Un-P1-T9
D-Link (Left group)
Optical HUB 7 Un-P1-T1-T1
Optical HUB 7 Un-P1-T1-T2
Optical HUB 6 Un-P1-T1-T3
Optical HUB 6 Un-P1-T1-T4
Optical HUB 5 Un-P1-T1-T5
Optical HUB 5 Un-P1-T1-T6
Optical HUB 4 Un-P1-T1-T7
Optical HUB 4 Un-P1-T1-T8
Optical HUB 7 Un-P1-T2-T1
Optical HUB 7 Un-P1-T2-T2
Optical HUB 6 Un-P1-T2-T3
Optical HUB 6 Un-P1-T2-T4
Optical HUB 5 Un-P1-T2-T5
Optical HUB 5 Un-P1-T2-T6
Optical HUB 4 Un-P1-T2-T7
Optical HUB 4 Un-P1-T2-T8
Optical HUB 7 Un-P1-T3-T1
