Table 6. FRU location (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Tape drive (USB) Un-P1-D2 No
Disk drive 1 Un-P2-D1 Yes See Disk drives.
Disk drive 2 Un-P2-D2 Yes
Disk drive 3 Un-P2-D3 Yes
Disk drive 4 Un-P2-D4 Yes
Disk drive 5 Un-P2-D5 Yes
Disk drive 6 Un-P2-D6 Yes
Disk drive 7 Un-P2-D7 Yes
Disk drive 8 Un-P2-D8 Yes
Solid-state disk drive 1 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D1 or Un -P1-C1-Cx-D1 No
Solid-state disk drive 2 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D2 or Un -P1-C1-Cx-D2 No
Solid-state disk drive 3 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D3 or Un -P1-C1-Cx-D3 No
Solid-state disk drive 4 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D4 or Un -P1-C1-Cx-D4 No
DVD Un-P2-D9 Yes
SAS port Un-P2-T1 No
Embedded SAS controller Un-P1-T9 No
Control panel
Control panel Un -D1 No See Control panel
and signal cables
for the 8202-E4B
or 8205-E6B
systems.
Temperature sensor Un -D1 No
Control panel - USB port Un -D1-T1 No
Server firmware
Server firmware Um-Y1
Related reference:
8202-E4B or 8205-E6B system parts
Indexed drawings show system part numbers for each part.
8231-E2B
The information provided in this topic defines specific sections of a location code string. Use this
information to understand the meaning of a location code.
Using location codes
Use the following table to link to a specific topic that you need additional information about when
reading your location code.
26 Finding parts, locations, and addresses
