Table 50. FRU locations and failing components (continued)
Failing item name Physical location code Identify LED Failing item removal
and replacement
procedures
Midplane Un-P1 Yes See Removing and
installing a
midplane.
Device physical locations
Disk drive 1 Un-P1-D1 Yes See Removing and
installing a disk
drive.
Disk drive 2 Un-P1-D2 Yes
Disk drive 3 Un-P1-D3 Yes
Disk drive 4 Un-P1-D4 Yes
Disk drive 5 Un-P1-D5 Yes
Disk drive 6 Un-P1-D6 Yes
Disk drive 7 Un-P1-D7 Yes
Disk drive 8 Un-P1-D8 Yes
Disk drive 9 Un-P1-D9 Yes
Disk drive 10 Un-P1-D10 Yes
Disk drive 11 Un-P1-D11 Yes
Disk drive 12 Un-P1-D12 Yes
Disk drive 13 Un-P1-D13 Yes
Disk drive 14 Un-P1-D14 Yes
Disk drive 15 Un-P1-D15 Yes
Disk drive 16 Un-P1-D16 Yes
Disk drive 17 Un-P1-D17 Yes
Disk drive 18 Un-P1-D18 Yes
Disk drive 19 Un-P1-D19 Yes
Disk drive 20 Un-P1-D20 Yes
Disk drive 21 Un-P1-D21 Yes
Disk drive 22 Un-P1-D22 Yes
Disk drive 23 Un-P1-D23 Yes
Disk drive 24 Un-P1-D24 Yes
Related reference:
5887 system parts
Indexed drawings show system part numbers.
5888 or EDR1 PCIe storage enclosure
The information provided in this topic defines specific sections of a location code string. Use this
information to understand the meaning of a location code.
Using location codes
Use the following table to link to a specific topic that you need additional information about when
reading your location code.
164 Finding parts, locations, and addresses
