8202-E4C, 8202-E4D, 8205-E6C, or 8205-E6D system parts
Indexed drawings show system part numbers for each part.
Rack final assembly
Table 75. Cover assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
1 46K5096 1 EIA bracket (left)
1 46K5097 1 EIA bracket (right)
2 39J0199 2 Attaching screw for EIA bracket
3 00E5669 2 Slide rail assembly
4 49Y5312 2 Attaching screw for slide rail assembly
5 74Y9017 1 Top access cover assembly (IBM)
5 74Y9018 1 Top access cover assembly (OEM)
6 68Y7211 1 Cable management arm assembly
7 46K4640 1 Front bezel (8202-E4C or 8202-E4D) (rack)
7 46K4639 1 Front bezel (8202-E4C or 8202-E4D) (stand-alone)
7 74Y5138 1 Front bezel (8205-E6C or 8205-E6D) (rack)
7 74Y5142 1 Front bezel (OEM) (rack)
194 Finding parts, locations, and addresses
