8202-E4C, 8202-E4D, 8205-E6C, or 8205-E6D addresses
You can cross-reference a disk drive physical location code to the address.
Use the address to find the location for the system, and then go to “8202-E4C, 8202-E4D, 8205-E6C, or
8205-E6D” on page 15 to find additional location information.
Table 54. IOA and device address information running IBM i
Position Possible failing item DSA (BBBBCcbb) Unit address
Un -P1 Embedded SAS
controller
000A0000 Not applicable
Un -P1-C19 RAID card 000C0000 Not applicable
Un -P1-C14 Split disk drive card Not applicable
Un -P1-C2 PCIe adapter 02010000
Un -P1-C3 PCIe adapter 02020000
Un -P1-C4 PCIe adapter 02030000 Not applicable
Un -P1-C5 PCIe adapter 02040000 Not applicable
Un -P1-C6 PCIe adapter 02050000 Not applicable
Un -P1-C7 PCIe adapter 02060000 Not applicable
Un -P1-C1-C1 PCIe adapter 020A0000 Not applicable
Un -P1-C1-C2 PCIe adapter 02090000 Not applicable
Un -P1-C1-C3 PCIe adapter 02070000 Not applicable
Un -P1-C1-C4 PCIe adapter 02080000 Not applicable
Un -P1-C19 RAID card or split disk
drive card
02020000 Not applicable
Un -P1-D1 Tape drive - SAS 02000000 070000FF
Un - P2-D9 DVD 02000000 060000FF
Un -P2-D1 Disk drive 1 000A0000 or 000C0000 000400FF
Un -P2-D2 Disk drive 2 000A0000 or 000C0000 000500FF
Un -P2-D3 Disk drive 3 000A0000 or 000C0000 000600FF
Un -P2-D4 Disk drive 4 000A0000 or 000C0000 000700FF
Un -P2-D5 Disk drive 5 000A0000 or 000C0000 000800FF
Un -P2-D6 Disk drive 6 000A0000 or 000C0000 000900FF
Un -P2-D7 Disk drive 7 000A0000 or 000C0000 000A00FF
Un -P2-D8 Disk drive 8 000A0000 or 000C0000 000B00FF
Un -P1-Cx-D1 or
Un -P1-C1-Cx-D1
Disk drive 1 on PCIe
SAS RAID and SSD
adapter
020x0000 000000FF
Un -P1-Cx-D2 or
Un -P1-C1-Cx-D2
Disk drive 2 on PCIe
SAS RAID and SSD
adapter
020x0000 010000FF
Un -P1-Cx-D3 or
Un -P1-C1-Cx-D3
Disk drive 3 on PCIe
SAS RAID and SSD
adapter
020x0000 040000FF
Un -P1-Cx-D4 or
Un -P1-C1-Cx-D4
Disk drive 4 on PCIe
SAS RAID and SSD
adapter
020x0000 050000FF
172 Finding parts, locations, and addresses
