System assembly detail
Table 70. System assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
8 2BCD 74Y5481 1 Control panel assembly
9 46K4646 1 Control panel cable (rack)
9 46K4645 1 Control panel cable (stand-alone)
10 74Y6301 1 Fan cage assembly
11 74Y5220 1 120 mm fan assembly
12 1 Tape drive. See Managing tape drives.
13 46K7514 1-4 Memory riser
14 2BCF 74Y6020 1 Cache battery card
15 51CB 74Y5451 2 Processor VRM
16 2BE1 46K7723 1 RAID enablement card
17 2BDA 46K7529 2 GX book assembly
18 266D 46K8121 1 Host Ethernet Adapter Quad 1 Gb copper card
18 266E 74Y2000 1 Host Ethernet Adapter Dual 10 Gb fiber card
Finding parts, locations, and addresses 189
