Table 3. FRU location (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Host Ethernet Adapter slot Un-P1-C3 Yes See Host Ethernet
adapter.
Host Ethernet Adapter 4-Port 1 Gb card
- Port 1
Un-P1-C3-T1 Yes
Host Ethernet Adapter 4-Port 1 Gb card
- Port 2
Un-P1-C3-T2 Yes
Host Ethernet Adapter 4-Port 1 Gb card
- Port 3
Un-P1-C3-T3 Yes
Host Ethernet Adapter 4-Port 1 Gb card
- Port 4
Un-P1-C3-T4 Yes
Host Ethernet Adapter 2-Port 10 Gb card
- Port 1
Un-P1-C3-T1 Yes
Host Ethernet Adapter 2-Port 10 Gb card
- Port 2
Un-P1-C3-T2 Yes
PCIe slot 1 Un-P1-C4 No See PCI
Adapters.
PCIe slot 2 Un-P1-C5 No
PCIe slot 3 Un-P1-C6 No
PCIe slot 4 Un-P1-C7 No
GX Dual-Port 12X Channel Attach
adapter
Un-P1-C8 Yes See GX++ 12X
channel adapters.
GX Dual-Port 12X Channel Attach
adapter
Note: You can either install the GX
Dual-Port 12X Channel Attach adapter
in Un-P1-C2 or the PCIe riser in
Un-P1-C1, but not both at the same time.
Un-P1-C2
GX Dual-Port 12X Channel Attach
adapter IB-2 card - Port 1
Un-P1-C8-T1 Yes
GX Dual-Port 12X Channel Attach
adapter IB-2 card - Port 2
Un-P1-C8-T2 Yes
PCIe expansion feature - Fan 1 Un-P1-C1-A1 Yes
PCIe expansion feature - Fan 2 Un-P1-C1-A2 Yes
System VPD card Un-P1-C20
RAID enablement card for system
backplane
Un-P1-C13 Yes See SAS RAID
enablement and
cache battery
pack.
Cache battery card Un-P1-C14 Yes
Battery on cache battery card Un-P1-C14-E1 Yes
RAID storage controller or RAID and
cache storage controller
Un-P1-C19 Yes
Battery on RAID and cache storage
controller
Un-P1-C19-E1 Yes
Memory modules
12 Finding parts, locations, and addresses
