Table 3. FRU location (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Memory card 3 - 20A memory VRM Un-P1-C16-C5 Yes See Memory
voltage regulator
module for the
8202-E4B or
8205-E6B.
Memory card 3 - 80A memory VRM Un-P1-C16-C6 Yes
Memory card 4 Un-P1-C15 Yes See Memory
modules.
Memory card 4 - DIMM 1 Un-P1-C15-C1 Yes
Memory card 4 - DIMM 2 Un-P1-C15-C2 Yes
Memory card 4 - DIMM 3 Un-P1-C15-C3 Yes
Memory card 4 - DIMM 4 Un-P1-C15-C4 Yes
Memory card 4 - DIMM 5 Un-P1-C15-C7 Yes
Memory card 4 - DIMM 6 Un-P1-C15-C8 Yes
Memory card 4 - DIMM 7 Un-P1-C15-C9 Yes
Memory card 4 - DIMM 8 Un-P1-C15-C10 Yes
Memory card 4 - 20A memory VRM Un-P1-C15-C5 Yes See Memory
voltage regulator
module for the
8202-E4B or
8205-E6B.
Memory card 4 - 80A memory VRM Un-P1-C15-C6 Yes
Device physical locations
Tape drive (SAS) Un-P1-D1 No
Tape drive (USB) Un-P1-D2 No
Disk drive 1 Un-P2-D1 Yes See Disk drives.
Disk drive 2 Un-P2-D2 Yes
Disk drive 3 Un-P2-D3 Yes
Disk drive 4 Un-P2-D4 Yes
Disk drive 5 Un-P2-D5 Yes
Disk drive 6 Un-P2-D6 Yes
Disk drive 7 Un-P2-D7 Yes
Disk drive 8 Un-P2-D8 Yes
Solid-state disk drive 1 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D1 or Un -P1-C1-Cx-D1 No
Solid-state disk drive 2 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D2 or Un -P1-C1-Cx-D2 No
Solid-state disk drive 3 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D3 or Un -P1-C1-Cx-D3 No
Solid-state disk drive 4 on PCIe SAS
RAID and SSD adapter
Un -P1-Cx-D4 or Un -P1-C1-Cx-D4 No
DVD Un-P2-D9 Yes
SAS port Un-P2-T1 No
Embedded SAS controller Un-P1-T9 No
14 Finding parts, locations, and addresses
