Table 134. Final assembly (front) (continued)
Index
number
CCIN Part number Units per
assembly
Description
5 2BBE 74Y9514 1 Small form factor SAS disk drive backplane with
embedded SAS adapters
Note: If feature code 5662 is not installed, the
embedded SAS adapters report CCINs of 57C7. If
feature code 5662 is installed, the embedded SAS
adapters report CCINs of 57CF.
6 2B9F 74Y3957 1 Control panel (9179-MHC)
6 2B01 00E1635 1 Control panel (8412-EAD, 9117-MMD, or
9179-MHD)
7 1 DVD drive. See Managing DVD drives.
8 00E5725 2 Cache battery pack
9 2BC2 00E5681 1 175 MB cache RAID and dual storage IOA
enablement card
Note: If feature code 5662 is installed, the
embedded SAS adapters report CCINs of 57CF.
10 1 - 6 See Disk drive and solid-state drive system parts.
252 Finding parts, locations, and addresses
