Table 24. FRU location table (continued)
Failing item name Physical location code Identify LED
Failing item
removal and
replacement
procedures
Processor Voltage Regulator Module 1
(Proc2 VRM)
Un-P3-C22 Yes
Processor Voltage Regulator Module 2
(Proc2 VRM)
Un-P3-C25 Yes
Processor Voltage Regulator Module 3
(Proc2 VRM)
Un-P3-C26 Yes
Processor Voltage Regulator Module 4
(Proc2 VRM)
Un-P3-C29 Yes
Memory Voltage Regulator Module 5
(Mem2 VRM)
Un-P3-C5 Yes
Voltage Regulator Module 6 (30P VRM) Un-P3-C6 Yes
Voltage Regulator Module 7 (30P VRM) Un-P3-C15 Yes
Memory Voltage Regulator Module 8
(Mem2 VRM)
Un-P3-C17 Yes
TPMD card Un-P3-C16 Yes
SCM - P7-0 Un-P3-C23
SCM - P7-2 Un-P3-C24
SCM - P7-3 Un-P3-C27
SCM - P7-1 Un-P3-C28
Fabric Bus A- P7 - 0 Bus cable connector Un-P3-T1
Fabric Bus B- P7- 0 Bus cable connector Un-P3-T2
Fabric Bus A- P7 -1 Bus cable connector Un-P3-T3
Fabric Bus B- P7- 1 Bus cable connector Un-P3-T4
Fan connector (leftmost) Un-P3-T5
Fan connector (second from left) Un-P3-T6
Fan connector (third from left) Un-P3-T7
Fan connector (second from right) Un-P3-T8
Fan connector (rightmost) Un-P3-T9
VPD card Un-P2- C7
Service processor
FSP cable A connector Un-P1-C1-T1 Yes
FSP cable drawer 4 connector Un-P1-C1-T1 Yes
FSP cable drawer 3 connector Un-P1-C1-T2 Yes
FSP cable drawer 1, 2 connector Un-P1-C1-T3 Yes
FSP cable drawer 5 connector Un-P1-C1-T4 Yes
FSP USB port Un-P1-C1-T5 Yes
Time-of-day (TOD) Un-P1-C1
Time-of-day battery Un-P1-C1-E1
HMC 1 connector Un-P1-C1-T6 Yes
80 Finding parts, locations, and addresses
