Table 60. Dimensions for rack (continued)
Rack
configuration
Width Depth Height Weight
(empty)
Weight
(maximum
configuration)
EIA unit
capacity
Rack with
standard rear
door only
644 mm (25.4
in.)
1042 mm (41.0
in.)
1804 mm (71.0
in.)
254 kg (559 lb) N/A N/A
Rack with
standard front
and rear doors
644 mm (25.4
in.)
1100 mm (43.3
in.)
1804 mm (71.0
in.)
268 kg (590 lb) N/A N/A
Rack with FC
6101 OEM
front door and
standard rear
door
644 mm (25.4
in.)
1100 mm (43.3
in.)
1804 mm (71.0
in.)
268 kg (590 lb) N/A N/A
Rack with FC
6068 high
perforation
front door and
standard rear
door
644 mm (25.4
in.)
1100 mm (43.3
in.)
1804 mm (71.0
in.)
268 kg (590 lb) N/A N/A
Rack with FC
6248 acoustic
front and rear
doors
644 mm (25.4
in.)
1413 mm (55.6
in.)
1804 mm (71.0
in.)
268 kg (589 lb) N/A N/A
1
For more information about rack weight distribution and floor loading, see 7014-T00, 7014-T42, and 0553 rack
weight distribution and floor loading.
Table 61. Dimensions for doors
Door model Width Height Depth Weight
Standard front door 639 mm (25.2 in.) 1740 mm (68.5 in.) 56 mm (2.3 in.) 14 kg (31 lb)
Standard rear door 639 mm (25.2 in.) 1740 mm (76.6 in.) 26 mm (1.0 in.) 11 kg (24 lb)
With acoustic foam:
14 kg (31 lb)
Standard side covers 10 mm (0.4 in.) each 1740 mm (68.5 in.)
each
1042 mm (41.0 in.)
each
18 lbs (8.25) kg each
FC 6101 front door
(OEM)
639 mm (25.2 in.) 1740 mm (68.5 in.) 56 mm (2.3 in.) 14 kg (31 lb)
FC 6068 front door,
high perforation
639 mm (25.2 in.) 1740 mm (68.5 in.) 56 mm (2.3 in.) 14 kg (31 lb)
FC 6248 acoustic
doors, front and rear
639 mm (25.2 in.)
each
1740 mm (76.6 in.)
each
198 mm (7.8 in.) each 12.3 kg (27 lb) each
Table 62. Electrical
1
Electrical characteristics Properties
Power source loading maximum in kVA
2
8.4 (FC 6117
3
)
8.4 (FC EPB8
3,4
)
Site and hardware planning 37
