IBM RS/6000 7014-S00

Mounting
Plates (2)
Location
Marks
Holes for
Anchor Bolts
Tapped Holes for
Rack Mounting Bolts
Mounting
Holes
Front of
Rack
Plastic Isolator
Washer (4)
Leveling Foot (4)
Plastic Isolator
Pad (4)
Rack-Mounting
Bolts
Rack-Mounting
Bolts
18. Tighten the four rack-mounting bolts into the two mounting plates.
19. Skip to “Step 5. Attach the Convenience Outlet Mounting Plates (Optional)” on
page 2-16.
Chapter 2. System Installation 2-11
