Step 5. Attach the Convenience Outlet Mounting Plates (Optional)
An optional feature of the -48 V DC Model S00 rack are mounting plates for
customer installed convenience AC electrical outlets. These mounting plates may be
installed at the base of the front and rear of the rack. In addition to providing a
mounting location for an electrical outlet, each plate has a lug and ground cable for
grounding the customer's test equipment.
Note: The customer is responsible for providing both the front electrical outlet
assembly and the power cable from the customer power source to the front
electrical outlet. The customer is also responsible for having the electrical
outlet assembly properly connected by a professional electrician. These
items are not field replaceable units.
1. If the customer does not want to connect an electrical outlet to the mounting
plate at this time, but wants the mounting plate installed, skip to step 4 on
page 2-17.
2. Remove the blank filler plate in the outlet opening on the mounting plate.
2-16 7014 Model S00 Rack Installation and Service Guide
