Chapter 2. Installing and configuring the switch
You can install the SAN48B-5 switch in the following ways:
v As a stand-alone unit on a flat surface. For instructions and more information,
see “Setting up the switch as a standalone unit” on page 7.
v In an Electronic Industries Association (EIA) cabinet using the fixed rack mount
kit, slide rack mount kit, or the mid-mount rack kit. For more information, see
“Installing in an EIA cabinet” on page 9.
This chapter provides the following information:
v “Items included with the switch”
v “Site preparation and installation requirements” on page 6
v “Setting up the switch as a standalone unit” on page 7
v “Installing in an EIA cabinet” on page 9
v “Configuring the switch” on page 14
Attention: Read the “Safety notices and labels” on page xiii before
attempting any installation, maintenance, or service procedures.
Items included with the switch
The following items are included with the standard shipment of the switch. When
you open the packaging, verify that these items are included in the package and
that no damage occurred during shipping.
Note: If any items are damaged or missing, within the United States and Canada,
contact the IBM Quality Hotline toll-free 1-800-442-6773 or direct dial in
other locations: 770-858-8459.
v The SAN48B-5 switch, containing two integrated power and fan assemblies
v 16 Gbps or 8 Gbps SFP+ modules for the Fibre Channel ports (speed and
quantity as ordered)
v One accessory kit, containing the following items:
– SAN48B-5 Installation, Service, and User Guide (this document).
– IBM documentation CD
– Safety notices
– Slim rail rack mount kit
– Serial cable with an RJ45 connector
– Two 6 ft. (1.8 m) country-specific power cord
– Rubber feet, required for setting up the switch as a standalone unit
– SAN48B-5 Quick Start Guide
– EZSwitch Setup CD
– Warranty
– Environmental notices
– Paperpack of optional features license and key activation information (if
ordered)
© Copyright IBM Corp. 2011, 2013 5
