IBM SAN48B-5

Access Gateway default port mapping
Table 16 lists the port mappings of F_Ports to N_Ports.
Table 16. Access Gateway default port mapping
Total
Ports F_Ports N_Ports Default port mapping
48 0-39 40-47 0-4 mapped to 40
5-9 mapped to 41
10-14 mapped to 42
15-19 mapped to 43
20-24 mapped to 44
25-29 mapped to 45
30-34 mapped to 46
35-39 mapped to 47
42 SAN48B-5 Installation, Service, and User Guide
