Table 25. Expansion canister and SAS port LEDs (continued)
Name Color State Meaning
▌5▐ and ▌7▐ SAS link
operational
Green Off No link connection on
any lane. The connection
is down.
On The SAS link is active. At
least one of the four
lanes is connected.
Storwize V5000 Gen2 2077-92F expansion enclosure parts
On the 2077-92F expansion enclosure, all replaceable parts are customer-replaceable
units (CRUs).
Note: All of the information that is listed in the following tables for the 2077-92F
expansion enclosure is also applicable to the 2078-92F expansion enclosure.
Expansion enclosure drives
Table 26 summarizes the part numbers and feature codes for the 2077-92F
expansion enclosure, which is supported by all Storwize V5000 Gen2 systems.
Table 26. Supported expansion enclosure SAS drives
Description FRU part number Feature code Comments
600 GB 15 K hard disk
drive
01LJ037 ACP0 Common to all Storwize
V5000 Gen2 systems, except
for Storwize V5030F
systems.
1.2 TB 10 K hard disk drive 01LJ038 ACP3
1.8 TB 10 K hard disk drive 01LJ039 ACP4
6 TB 7.2 K Near-Line SAS
hard disk drive
01LJ040 ACP7
8 TB 7.2 K Near-Line SAS
hard disk drive
01LJ041 ACP8
10 TB 7.2 K Near-Line SAS
hard disk drive
01LJ042 ACP9
1.6 TB tier 0 flash drive 01LJ043 ACPD For systems with a 1-year
warranty (2077-xxx).
ACQD For systems with a 3-year
warranty (2078-xxx).
3.2 TB tier 0 flash drive 01LJ044 ACPE For systems with a 1-year
warranty (2077-xxx).
ACQE For systems with a 3-year
warranty (2078-xxx).
1.92 TB tier 1 flash drive 01LJ045 ACPJ For systems with a 1-year
warranty (2077-xxx).
ACQJ For systems with a 3-year
warranty (2078-xxx).
142 Storwize V5000 Gen2: Quick Installation Guide
