v Always use a suitably rated mechanical lift or four persons when you are
performing any of the following tasks:
– Removing the expansion enclosure from its packing material
– Lifting and installing the expansion enclosure in the rack for the first time
– Reinstalling the expansion enclosure after you complete a service task (for
example, replacing the enclosure FRU).
v At least three persons are required to move the 2077-92F enclosure while it is in
the rack (if you are moving the enclosure off the rails). Even after the drives,
power supply units, secondary expander modules, canisters, fans, and top cover
are removed, the enclosure weighs approximately 43 kg (95 lbs).
v To maximize rack stability, always install the expansion enclosure in the lowest
possible position in the rack.
Weight of expansion enclosure parts
Table 14 summarizes the weight and quantity of the parts (FRUs) that are shipped
with the 2077-92F expansion enclosure.
Table 14. Weight of expansion enclosure parts
FRU
description
FRU part
number
Weight per unit
Quantity
shipped
Total weight
kg lbs kg lb
Enclosure FRU 01LJ607
(replaces
enclosure FRU
P/N 01LJ112)
42.5 93.696 1 42.500 93.696
Rail kit 01LJ114 9.231 20.351 1 9.231 20.351
Front fascia
(4U front
cover)
01LJ116 0.303 0.668 1 0.303 0.668
Display panel
assembly
01LJ118 0.020 0.044 1 0.020 0.044
PSU fascia (1U
cover)
01LJ120 0.010 0.022 1 0.010 0.022
Power supply
unit (PSU)
01LJ122 3.335 7.352 2 6.670 14.705
Secondary
expansion
module
01LJ860 (for
use with
enclosure FRU
P/N 01LJ607)
01LJ124 (for
use with
enclosure FRU
P/N 01LJ112)
0.826 1.821 2 1.652 3.642
Fan module 01LJ126 0.890 1.962 4 3.560 7.848
Expansion
canister
01LJ128 1.588 3.501 2 3.176 7.002
Cable
management
arm (lower
and upper
arms)
01LJ130 1.373 3.027 1 1.373 3.027
36 Storwize V5000 Gen2: Quick Installation Guide
