▌1▐ Power cable connector for PSU 2
▌2▐ Power cable retention clamps
▌3▐ Fan module
▌4▐ Fan release latch
▌5▐ Fan fault indicator
▌6▐ Expansion canister
▌7▐ SAS ports and indicators
▌8▐ Expansion canister indicators
▌9▐ Power cable connector for PSU 1
Support rails
Figure 25 on page 44 shows the support rails for the expansion enclosure. The
support rails are packaged separately from the expansion enclosure.
Figure 24. Features on the rear of the 2077-92F expansion enclosure
Chapter 2. Installing the system hardware 43
