IBM System x3250 M4 13
Storage host bus adapters
The following table lists the storage host bus adapters (HBAs) supported by x3250 M4 server.
Table 11. Storage adapters
Part number Description Maximum quantity
supported
Fibre Channel
46M6049 Brocade 8 Gb FC Single-port HBA for IBM System x 1
46M6050 Brocade 8 Gb FC Dual-port HBA for IBM System x 1
42D0485 Emulex 8 Gb FC Single-port HBA for IBM System x 1
42D0494 Emulex 8 Gb FC Dual-port HBA for IBM System x 1
42D0501 QLogic 8 Gb FC Single-port HBA for IBM System x 1
42D0510 QLogic 8 Gb FC Dual-port HBA for IBM System x 1
Converged Network Adapters (CNA)*
42C1820 Brocade 10 Gb Dual-port CNA for IBM System x 1
42C1800 QLogic 10 Gb Dual Port CNA for IBM System x 1
SAS
46M0907 IBM 6 Gb SAS HBA Controller 1
* Note: Converged Network Adapters require SFP+ optical transceivers or DAC cables that must be purchased
separately.
PCIe SSD adapters
The server does not support the High IOPS SSD adapters.
Power supplies
Some models include one fixed 300 W AC 80 PLUS-certified power supply. This 300 W unit cannot be
upgraded. Some models include one IBM 460W hot-swap power supply. With the addition of a second
power supply, the two form a redundant pair. The following table lists the option for the second power
supply.
Table 12. Power supply option
Part number Description
94Y6236 IBM 460W Redundant Power Supply
Both the 300W and 460W power supply units support maximum configurations and support auto restart
that minimizes operator intervention after a temporary power outage.
One 2.8-m C13 - C14 power cord is shipped for each included power supply.
