The following table lists the RAID controllers and additional options used for internal disk storage of x3250
M4 server. Either a ServeRAID BR10il v2, ServeRAID M1015, or ServeRAID M5014 is required for
models with 2.5" simple-swap SAS drive bays or 2.5" hot-swap SAS drive bays.
Table 7. RAID controllers for internal storage
Part number Description Maximum quantity
supported
Standard models
where used
49Y4731 ServeRAID-BR10il SAS/SATA Controller v2 1 72x
46M0831 ServeRAID M1015 SAS/SATA Controller 1 -
46M0832 ServeRAID M1000 Series Advance Feature Key 1 -
46M0916 ServeRAID M5014 SAS/SATA Controller 1 -
If the BR10il v2 controller is used, it is installed in slot 1 (PCIe x4). Other RAID controllers are installed in
slot 2 (PCIe x8), and slot 1 is left vacant. Only one RAID controller can be used with the server to support
internal HDDs. Features of the supported RAID controllers are discussed below.
The ServeRAID BR10il v2 SAS/SATA Controller has the following specifications:
One Mini-SAS internal connector

Supports RAID levels 0, 1, and 1E

3 Gbps throughput per port

Based on the LSI 1064E controller

PCI Express 2.0 x4 host interface

Stripe size: 64 KB (fixed)

For more information, see the ServeRAID-BR10il SAS/SATA Controller v2 for IBM System x at-a-glance
guide: http://www.redbooks.ibm.com/abstracts/tips0741.html?Open
The ServeRAID M1015 SAS/SATA Controller has the following specifications:
Two Mini-SAS internal connectors

Supports RAID levels 0, 1, and 10

Supports RAID levels 5 and 50 with optional ServeRAID M1000 Series Advanced Feature Key

6 Gbps throughput per port

Based on the LSI SAS2008 6 Gbps RAID on Chip (ROC) controller

PCI Express 2.0 x8 host interface

Configurable stripe size up to 64 KB

For more information, see the ServeRAID M1015 SAS/SATA Controller for System x at-a-glance guide:
http://www.redbooks.ibm.com/abstracts/tips0740.html?Open
The ServeRAID M5014 SAS/SATA Controller has the following specifications:
Two Mini-SAS internal connectors

Supports RAID levels 0, 1, 5, 10, and 50

6 Gbps throughput per port

PCI Express 2.0 x8 host interface

Based on the LSI SAS2108 6 Gbps RAID on Chip (ROC) controller

256 MB of onboard cache

For more information, see the ServeRAID M5015 and M5014 SAS/SATA Controllers for IBM System x
at-a-glance guide: http://www.redbooks.ibm.com/abstracts/tips0738.html?Open

IBM System x3250 M4 Specifications

General

Processor	Intel Xeon E3-1200 v2 series
Max Processors	1
Memory Slots	4
Network Interface	2 x Gigabit Ethernet
Memory	Up to 32 GB
Storage	Up to 4 x 3.5-inch or 8 x 2.5-inch drives
RAID Support	RAID 0, 1, 10
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Chipset	Intel C204
