Table 13. Memory-mirroring mode DIMM population sequence for the memory expansion
module (continued)
Sets of 4 DIMMs DIMM connector population sequence
Set 3 11, 14, 26, 31
Set 4 3, 6, 18, 23
Set 5 10, 15, 27, 30
Set 6 2, 7, 19, 22
Set 7 12, 13, 25, 32
Set 8 4, 5, 17, 24
Note: When you populate DIMMs in the memory expansion module,
populate the larger capacity DIMMs first, then the smaller capacity DIMMs.
86 IBM System x3850 X5 and x3950 X5 Types 7145, 7146, 7143, and 7191: Installation and User's Guide
