http://www.ibm.com/supportportal/. The documentation provides additional
installation and configuration information that you must follow before you use
the memory expansion module.
Table 1. Features and specifications
Microprocessor:
v Intel Xeon EX versions of the 6000
and 7000 Series or E7 Series
multi-core microprocessor with up
to 24 MB or 30 MB last level cache.
v 1066 MHz front-side bus (FSB)
v Support for up to four
microprocessors
– Four Quick Path Interconnect
(QPI) links per microprocessor at
up to 6.4 GT/s (gigatransfers per
second)
– Four Scalable Memory
Interconnect (SMI) links per
microprocessor at up to 6.4 GT/s
Note: Use the Setup utility to
determine the type and speed of the
microprocessors. The server does not
support mixing microprocessor types.
Memory:
v Type: Registered, ECC, PC3-10600
double data rate (DDR) III, SDRAM
v Sizes: 1 GB (Types 7145 and 7146
only) and 2 GB (PC3-10600 running
at 1066 Mb/sec), 4 GB, 8 GB, 16
GB, and 32 GB (when available)
(PC3-8500 running at 1066 Mb/sec)
in pairs
v Minimum (Types 7145 and 7146): 2
GB (two DIMMs per memory card
minimum)
v Minimum (Types 7143 and 7191): 4
GB (two DIMMs per memory card
minimum)
v Maximum: 1 TB (2 TB when 32 GB
DIMMs are available) (eight
memory cards, each card
containing 8 DIMM connectors for
a total of 64 DIMMs)
v Connectors: Two-way interleaved,
eight dual inline memory module
(DIMM) connectors per memory
card
v Supports 1.35-volt (low-voltage)
and 1.5-volt registered DIMMs
v Machine Types 7145 and 7146 uses
the Intel 7500 Scalable Memory
Buffer only
v Machine Types 7143 and 7191 uses
the Intel 7510 Scalable Memory
Buffer only
Expansion slots:
v Six non-hot-swap PCI Express x8
(three full-length and three
half-length) slots
v One non-hot-swap PCI Express
x16 (full-length) slot
v Emulex 10 GbE Custom Adapter
for IBM System x in slot 7
(optional in some models)
Upgradeable microcode:
System UEFI, FPGA, diagnostics,
service processor, IMM, and SAS
microcode
Power supply:
v Standard: One or two dual-rated
power supplies (depending on the
model).
– 1975 watts at 220 V ac input
– 875 watts at 110 V ac input
v Hot-swappable and redundant at
220 V ac, only with two power
supplies
v If the server is operating at 110 V
ac, a second power supply must
be installed.
Size:
v 4U
v Height: 172.8 mm (6.81 in.)
v Depth: 712.13 mm (28.04 in.)
v Width: (without rack EIA
brackets) 440 mm (17.32 in.)
v Width: (with rack EIA brackets)
482.6 mm (19 in.)
v Weight: approximately 49.90 kg
(110 lb) when fully configured
Drives:
v Slim CD/DVD-ROM: SATA
(optional)
v Serial Attached SCSI (SAS)
2.5-inch hard disk drives
(optional)
v Solid state 1.8-inch drives
(optional)
Expansion bays:
v Eight SAS, 2.5-inch bays or sixteen
solid state 1.8-inch bays
v One 12.7 mm removable-media
drive bay (CD/DVD drive
optional)
Acoustical noise emissions:
v Sound power, idle: 5.8 bel declared
v Sound power, operating: 6.3 bel
declared
Airflow:
v Nominal airflow: 67 cubic feet per
minute (CFM)
v Typical airflow: 100 CFM
v Maximum airflow: 241 CFM
Environment:
v Air temperature:
– Server on:
- 10°C to 35°C (50°F to 95°F);
altitude: 0 to 914 m (3000 ft).
- 10°C to 32°C (50°F to 90°F);
altitude: 914 to 2133 m (7000
ft).
– Server off: 10°C to 43°C (50.0°F to
109.4°F); maximum altitude: 2133
m (6998.0 ft)
v Humidity:
– Server on: 8% to 80%
– Server off: 8% to 80%
v Particulate contamination:
Attention: Airborne particulates
and reactive gases acting alone or in
combination with other
environmental factors such as
humidity or temperature might pose
a risk to the server. For information
about the limits for particulates and
gases, see “Particulate
contamination” on page 121.
Heat output:
Approximate heat output:
v Minimum configuration: 648 Btu per
hour (190 watts)
v Typical configuration: 3753 Btu per
hour (1100 watts)
v Design maximum configuration:
– 5971 Btu per hour (1930 watts) at
110Vac
– 6739 Btu per hour (2150 watts) at
220Vac
6 IBM System x3850 X5 and x3950 X5 Types 7145, 7146, 7143, and 7191: Installation and User's Guide
