1-2 Chapter 1
You will connect to the host you specified in the connection definition
selected. Connection definitions appearing in the Connections list can be
edited. To edit:
1 Select the connection that you want to edit from the Connections list.
2 Click on the Setup command button in the Connections dialog box.
3 Click on the Properties command button in Connection Setup dialog box.
The Connection Properties dialog box displays. Use this dialog box to edit
your preexisting connection definition.
New Connection
Definitions
If the connection definition you want does not already exist in the Connections
list, you can create one by:
1 Click on the Setup command button in the Connections dialog box.
2 Click on the New command button in the Connection Setup dialog box.
3 Click on the Terminal Emulation radio button, then the OK command button
in the New Connection dialog box.
❖
Note See your terminal’s connectivity guide for more information about
instructions 1 through 3 above. Refer to Figure 1-1, the Connection Properties
dialog box, while executing instructions 4 through 8.
Figure 1-1 Connection Properties Dialog Box
4 Click on the TN5250 radio button in the Terminal Type group box.
5 Enter a connection description (a name you choose) in the Description
entry field.
To Next Page
