IBM ThinkPad R30 Hardware Maintenance Manual

v “1090 LCD assembly” on page 174
v “1210 LCD bezel assembly (13.3″)” on page 188
1
Step Size (Quantity) Color Torque
1 M2 x L10(4) Black 2.5 kgf-cm
1230 LED board (13.3″)
v “1010 Battery assembly” on page 166
v “1020 Mini-PCI cover and Mini-PCI card” on page 166
v “1030 Memory cover and Memory card” on page 168
v “1060 Keyboard” on page 170
v “1080 Middle cover” on page 173
v “1090 LCD assembly” on page 174
v “1210 LCD bezel assembly (13.3″)” on page 188
1
2
190 ThinkPad R30/R31 HMM
