IBM ThinkPad T41 series User Manual

2020 Inverter card
For access, remove these FRUs in order:
v “1010 Battery pack” on page 68
v “1030 Hard disk drive” on page 71
v “1050 Keyboard” on page 75
v “1080 Bluetooth/Modem daughter card (BMDC)” on
page 82
v “1090 Palm rest” on page 84
v “1100 Mini PCI adapter” on page 86
v “1150 Keyboard bezel” on page 96
v “1160 LCD assembly” on page 98
v “2010 LCD front bezel” on page 116
1
2
3
4
Step Screw (quantity) Color Torque
1 M2 × 3 mm, small-head,
nylon-coated (1)
Silver 0.245 Nm
(2.5 kgfcm)
When installing: Make sure that connectors 2 and 3
are firmly attached.
Cable routing: When replacing the inverter card, route
the connector cable as in this figure:
Removing and replacing a FRU
118 MT 2373/2374/2375/2376/2378/2379

IBM ThinkPad T41 series Specifications

General

Operating System	Windows XP Professional
Weight	2.2 kg (4.9 lbs)
Chipset	Intel 855PM
Processor	Intel Pentium M
Display	14.1 inch
RAM	256 MB to 2 GB
Storage	30 GB to 80 GB HDD
Dimensions	311 x 255 x 26-30 mm
Display Resolution	1024x768 (XGA) or 1400x1050 (SXGA+)
Optical Drive	DVD-ROM, CD-RW/DVD-ROM Combo
Wireless	802.11b or 802.11g
Ethernet	10/100 Mbps
Battery	6-cell Li-Ion
Networking	Modem and Ethernet
Ports	2 USB 2.0, VGA, parallel, serial, infrared
Graphics	ATI Mobility Radeon 7500
Hard Drive Interface	Ultra ATA/100
