Lift the latch bar in the direction of the arrow 2, and then
remove the left latch in the direction of the arrow 3.
2
3
When installing: Attach the left latch to the LCD cover as
follows:
2
1
(continued)
Removing and replacing a FRU
122 MT 2373/2374/2375/2376/2378/2379

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the IBM ThinkPad T41 series and is the answer not in the manual?

IBM ThinkPad T41 series Specifications

General IconGeneral
Operating SystemWindows XP Professional
Weight2.2 kg (4.9 lbs)
ChipsetIntel 855PM
ProcessorIntel Pentium M
Display14.1 inch
RAM256 MB to 2 GB
Storage30 GB to 80 GB HDD
Dimensions311 x 255 x 26-30 mm
Display Resolution1024x768 (XGA) or 1400x1050 (SXGA+)
Optical DriveDVD-ROM, CD-RW/DVD-ROM Combo
Wireless802.11b or 802.11g
Ethernet10/100 Mbps
Battery6-cell Li-Ion
NetworkingModem and Ethernet
Ports2 USB 2.0, VGA, parallel, serial, infrared
GraphicsATI Mobility Radeon 7500
Hard Drive InterfaceUltra ATA/100
